Assembly Instructions - Mocka Activity Table Assembly Instructions Manual

Activity Table

Assembly Instructions

1
x 2
A
A
A
A
A A
A
A
A
4
Begin assembly by screwing in 24x bolts (A) into all corresponding
holes as shown in both panels [4] using a Phillips screwdriver. Take
care not to overtighten bolts.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
A
A
A
A
2
x 2
A
C
3
C
A
x24
Screw in 2x bolts (A) and insert 2x dowels (C) into holes in each of the
panels [1] and [3]. Slot together with the rest of panel [2] as shown.
Place locking 4x nuts (B) into holes in the panel and tighten with
screwdriver. Repeat step.
A
C A
B
B
1
2
C
A
B
B
x4
B
x4
2
