Water
Resistance
Notice: The abovementioned parameters (lab-tested by using two Fenix 3.6V/2600mAh
rechargeable 18650 Li-ion batteries) may vary between headlamps, batteries and environments.
◎ Uses Cree XM-L2 and XP-G2 R5 LED's with a lifespan of 50,000 hours
◎ Powered by two 18650 or four CR123A batteries
◎ Headlamp: 77mm Length x 52mm Width x 34mm Height
Battery case: 115mm Length x 56mm Width x 30mm Height
◎ Weight: 285 grams (excluding batteries)
Accessories: cable clip, top headband mount, spare O-ring, belt clip, USB charging cable,
◎
2*cable buckle, 2* Fenix 3.6V/2600mAh 18650 rechargeable Li-ion batteries
◎ Lockout function for safe and convenient carrying
◎ Free switching between spot- and neutral white floodlight, or use them simultaneously
◎ Belt-worn battery case can be placed in pocket or backpack, which reduces the load bearing
of user's head and maintains optimal performance in cold areas
◎ The battery case can be used as a power bank for charging other digital devices
◎ The 18650 batteries are charged alternately via Micro USB port for balanced battery level
◎ 60° tilt mechanism directs the beam where needed
◎ Reverse polarity protection, to protect from improper battery insertion
◎ Aluminum alloy die-casting design for security and better heat dissipation
◎ Toughened ultra-clear glass lens with anti-reflective coating

Operating Instruction

Lighting Mode (Factory default is "High" upon first use; thereafter intelligent memory circuit is
activated)
Spotlight switch
spotlight. Click to cycle through High→Turbo→Low→Med.
Floodlight switch
floodlight. Click to cycle the lamp through High→Turbo→Low→Med.
Note: The spot- and floodlights are controlled by separate switches.
Intelligent Memory Circuit
The headlamp memorizes the last brightness level used. When next turned on, the previously
used brightness level is recalled.
: press and hold the switch for 0.5 seconds to turn ON/OFF the
: press and hold the switch for 0.5 seconds to turn ON/OFF the
IP66
