User Manual
WISE-221X
IoT Wireless Sensor Node

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WISE-221 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech WISE-221 Series

Summary of Contents for Advantech WISE-221 Series

  • Page 1 User Manual WISE-221X IoT Wireless Sensor Node...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
  • Page 4 Warnings, Cautions and Notes Warning! Warnings indicate conditions, which if not observed, can cause personal injury! Caution! Cautions are included to help you avoid damaging hardware or losing data. e.g.There is a danger of a new battery exploding if it is incorrectly installed.
  • Page 5 Note! Antenna for NA series should be ordered respectively based on the required frequency range.  1750008836-01 863-870MHz Dipole Antenna for WISE-4210/ 2210/2211  1750008837-01 902-928MHz Dipole Antenna for WISE-4210/ 2210/2211 Safety Instructions Read these safety instructions carefully. Keep this User Manual for later reference. Disconnect this equipment from any AC outlet before cleaning.
  • Page 6 DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. WISE-221X User Manual...
  • Page 7 NCC 警语 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得 擅自變更頻率、加大功率或變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾 現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法 規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波 輻射性電機設備之干擾。 Frequency Type Gain Brand Part Number 863-870 MHz Dipole 2.02 dBi Advantech 1750008836-01 902-928 MHz Dipole 1.48 dBi Advantech 1750008837-01 WISE-221X User Manual...
  • Page 8 WISE-221X User Manual viii...

  • Page 9: Table Of Contents

    Contents Chapter Product Overview ........1 Series Family and Specifications .............. 2 Features ....................2 System Architecture .................. 2 Figure 1.1 System Architecture ........... 3 Mechanical Design and Dimensions ............3 Figure 1.2 WISE-221X Dimension Front and Side ...... 3 LED ......................4 Figure 1.3 LED of USB and COM..........
  • Page 10 Chapter System Configuration....... 19 Connection....................20 Figure 4.1 Connection WISE-221X and WISE-4210-AP ... 20 Configuring WISE-4210-AP with Browser..........21 4.2.1 System Requirements ..............21 4.2.2 Factory Default Settings ............. 21 4.2.3 Module Authorization ..............22 Install WISE Studio and Configure End Devices ........23 Connection between AP and Nodes ............

  • Page 11: Chapter 1 Product Overview

    Chapter Product Overview...

  • Page 12: Series Family And Specifications

    WISE-2211 to acquire sensor data from analog inputs connected to the 4~20mA sensor transmitter. WISE-221x transmits sensor data to WISE-4210-AP via Advantech LPWAN wireless technology. WISE-4210-AP provides Ethernet and RS- 485 connectivity, and supports Modbus, RESTful Web API, and iSensing MQTT pro- tocols for integration.

  • Page 13: Mechanical Design And Dimensions

    Figure 1.1 System Architecture Mechanical Design and Dimensions Figure 1.2 WISE-221X Dimension Front and Side Note! User need to install antenna when you use WISE-2210/2211 WISE-221X User Manual...

  • Page 14: Led

    Figure 1.3 LED of USB and COM Color Behavior Description Flash when data transmission: Transmit data to AP Green Always on: In bootloader mode (RF Tx) Idle USB connector plug in Green USB connector plug out Reset button Figure 1.4 Reset button WISE-221X User Manual...

  • Page 15: Chapter 2 Product Specification

    Chapter Product Specification...

  • Page 16: Wireless Interface

    Wireless Interface  IEEE Standard: IEEE 802.15.4g  Operating Frequency: – NA923: 923MHz (920.8~924.4), BW:400KHz – EU868: 868MHz (865.2~868.8), BW:400KHz  Data Rate: 625bps / 2.5k bps / 5k bps / 50k bps  Antenna Gain – 902~928MHz: 1.48 dBi –...

  • Page 17: General

    General  I/O & Power connector: 3.5-mm spacing plug-in screw terminal block  Enclosure: PC  Mounting: DIN 35 rail, wall, pole  Dimensions (W x H x D): 71 x 52 x 30 mm (without Antenna)  Operation temperature: -25~70°C (-13~158°F) ...

  • Page 18: Wise-2211

    2.3.2 WISE-2211 Input power requirements: WISE-2211 is a self-powered sensor node, power source is obtained from analog inputs connected through a 4~20mA sensor transmitter. In other words, WISE-2211 measures data and gets power current from a connected sensor transmitter. Charging time Data Transmission 1st Charging Time Data rate...

  • Page 19: I/O Specifications

    Note! To order an Advantech CT (Current Transformer), refer to section 2.11.Accessory: CT (Current Transformer). If the user wants to choose a CT themselves, please make sure the ratio of Np:Ns is above 1:3000, and the output range of the CT secondary current value is between 0-100(mA).

  • Page 20: Pin Assignment

    Pin Assignment Figure 2.3 WISE-221X Pin Assignment Application Wiring WISE-2210 Analog input current: Alternating Current (0~100 mA) Figure 2.4 WISE-2210 I/O Pinout & Application Wiring WISE-2211 Analog input current: Direct Current (4~20mA) WISE-221X User Manual...

  • Page 21: Block Diagram

    Figure 2.5 WISE-2211 I/O Pinout & Application Wiring 2.10 Block Diagram Figure 2.6 WISE-2210/2211 Block Diagram 2.11 Accessory: CT (Current Transformer) To order an Advantech CT (Current Transformer) see below: Power Current Hole sizing Accuracy Operating Range (Primary (Primary) Temperature...
  • Page 22 WISE-221X User Manual...

  • Page 23: Chapter 3 Mechanical And Hardware Installation

    Chapter Mechanical and Hardware Installation...

  • Page 24: Interface Introduction

    Interface Introduction Figure 3.1 WISE-221x Interface Introduction WISE-221X User Manual...

  • Page 25: Mounting

    Mounting Applicable installation methods are briefly described in the following sections. 3.2.1 Poll Mount Use a screwdriver to fasten WISE-221X and mounting kit. Then use a cable tie to fasten the mount kit and pole. Figure 3.2 Pole Mounting (front) Figure 3.3 Pole Mounting (back) WISE-221X User Manual...

  • Page 26: Wall Mounting

    3.2.2 Wall Mounting WISE-221X can be fixed to a wall with a mounting kit. Use a screwdriver to fasten the mounting adapter to your module, and use the end brackets included in the package in order to keep it from sliding. Figure 3.4 Wall Mounting Install Figure 3.5 Wall Mounting Install WISE-221X User Manual...

  • Page 27: Din-Rail Mounting

    3.2.3 DIN-Rail Mounting WISE-221X can be fixed to a cabinet with mounting rails. Use a screwdriver to fasten the DIN rail adapter to your module, and use the end brackets included in the pack- age in order to keep it from sliding. Note! DIN-Rail Mounting adapter for WISE-221X is available for ordered: ...

  • Page 28: Power Supply Wiring

    Figure 3.8 DIN Mounting Install (Back) Power Supply Wiring WISE-221X is a self-powered sensor node, power source is obtained from the analog input channels. WISE-221X User Manual...

  • Page 29: System Configuration

    Chapter System Configuration...

  • Page 30: Connection

    Connection Connect WISE-221X to your computer via a micro-B USB port. The USB driver is required for creating a virtual COM port with your computer. Please refer to the following link to get the latest USB driver: CP210x USB to UART Bridge VCP Drivers: https://www.silabs.com/products/development-tools/software/usb-to-uart-bridge-vcp- drivers...

  • Page 31: Configuring Wise-4210-Ap With Browser

    Configuring WISE-4210-AP with Browser 4.2.1 System Requirements The web utility of WISE-4210-AP is developed with HTML 5, but for detailed indica- tion and data transmission mode, the type of web utility will depend on web page of the operating system. For mobile devices, the minimum system requirements of web browsers are as below: Safari 6 in Apple iOS...

  • Page 32: Module Authorization

    4.2.3 Module Authorization Account Default Password Access Ability root 00000000 All privileges All privileges except change, reset password and reset to admin 00000000 default View module status only. user 00000000 Not allow to change configurations Functions Account root admin user Device information View View...

  • Page 33: Install Wise Studio And Configure End Devices

    Install WISE Studio and Configure End Devices Step 1. Download and install WISE Studio through the following link: https://support.advantech.com/support/new_default.aspx Step 2. Execute WISE Studio Step 3. Power up WISE-4210-AP. Step 4. Use a USB cable to communicate WISE-221x through a computer.

  • Page 34: Connection Between Ap And Nodes

    Step 7. Once everything is all set, you are successfully into configuration page. Connection between AP and Nodes The first step of the connection between WISE-221x devices and WISE-4210-AP is to configure the units in the same network with the same frequency range. Please go to End Devices \ RF Status \ Configuration to configure the RF module by following the instructions below.

  • Page 35: Configure Wise-4210-Ap

    Configure WISE-4210-AP Step 1. The default IP address of WISE-4210-AP is 10.0.0.1, if you are not able to access WISE-4210-AP, please follow step 2 to search the IP address of WISE-4210- Step 2. Configure the Ethernet adapter under the same subnet as 10.0.0.1. In the fol- lowing figure, the IP address of this computer is configured as 10.0.0.100.
  • Page 36 Step 5. Go to Configuration \ Network to configure LAN port parameters of WISE- 4210-AP. Step 6. Go to Configuration \ RF Module to configure the RF module  RF Operation Mode: WISE-221x devices supports Push Mode, the communi- cation from the end node device to AP is uplink only, no downlink. ...

  • Page 37: Setup Wise-221X Network

    Setup WISE-221x Network After configuring all end devices into the same network with WISE-4210-AP, users can go to End Devices tab to check End Device List.  MAC Address: The unique identifier of each end devices.  Modbus ID: Modbus ID is automatically assigned by WISE-4210-AP. User can configure Modbus ID manually in Configuration \ Modbus \ Modbus ID.

  • Page 38: I/O Status

    CT Secondary Current Value is the power current WISE-2210 is using. Note! Users can order Advantech accessory: CT (Current Transformer), please see chapter 2.11.Accessory: CT (Current Transformer). If the user wants to choose a CT themselves, please make sure the ratio Np:Ns is above 1:3000, and the output range of the CT Secondary Cur- rent value is between 0-100(mA).

  • Page 39: Access Wise-221X Data By Modbus/Tcp Protocol

    Access WISE-221x Data by Modbus/TCP Protocol Go to Configuration \ Modbus \ Modbus ID to check and configure the Modbus ID of each MAC address of AP and end node devices. User can use Modbus/TCP and Modbus/RTU protocol to access each end devices from WISE-4210-AP, polling data from different Modbus ID for different end node devices, or AP.
  • Page 40 Modbus Address Table for WISE-2210 and 2211: Address 4X Description Attribute 40001 Read 40002 Read 40003 Read 40004 Read 40005 AI Value Read 40006 Read 40007 Read 40008 Read 40009 Average Ch 0~7 Read 40131~40132 Read 40133~40134 Read 40135~40136 Read 40137~40138 Read AI Floating Value...

  • Page 41: Push Wise-4210 Data By Restful Web Service

    Push WISE-4210 data by RESTful Web Service Step 1. Configure the Private Server in Configuration \ Cloud. Step 2. Enable the Data Logger function in Advanced \ Data Logger \ Logger Configuration WISE-221X User Manual...

  • Page 42: Access Wise-4210 I/O Data By Restful Api

    4.10 Access WISE-4210 I/O Data by RESTful API /lpwan_message/slot_macID Description Retrieves the log data in system memory. URL Structure http://10.0.0.1/lpwan_message/slot_macID GET: According to the setting of filtering, server returns the all/partial of HTTP Method push data. Request: GET / lpwan_message/slot_macID [Example]: ...
  • Page 43 Timestamp of the storage – Coordinated Universal Time (UTC) Ex. "1415757750" corre- sponds to November 12, 2014, 2:02:30 am, Stan- dard Time. (meanwhile, 2014, 10:02:30 am, Taipei Time.) Timestamp String – Local Date/Time according GMT time zone (ISO 8601) Ex. "1994-11-05T08:15:30- 05:00"...
  • Page 44 [I/O Type Index Table] Index Recording I/O-type of the storage Invalid DI Logic Status DI Counter value DI Frequency value DO Logic Status DO Absolute Pulse Output value DO Incremental Pulse Output Value AI value Historical Maximum AI value Historical Minimum AI value AI value after scaling AI status flags AI engineering value...
  • Page 45 WISE-221X User Manual...
  • Page 46 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2019...

This manual is also suitable for:

Wise-2210Wise-2211
