Summary of Contents for Advantech WISE-4471 Series
- Page 1 User Manual WISE-4471 Series...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 This equipment complies with FCC radiation exposure limits set forth for an uncon- trolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. NCC 警語 電磁波警語標示： 「減少電磁波影響，請妥適使用」 。 WISE-4471 Series User Manual...
- Page 4 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
- Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 6 Don't touch any components on the CPU card or other cards while the PC is on. Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. WISE-4471 Series User Manual...
-
Page 7: Table Of Contents
......9 Interface Introduction ................10 Figure 3.1 WISE-4471 Interface Introduction ......10 Mounting ....................10 Figure 3.2 WISE-4471 Series Mounting Kit Dimensions ... 10 3.2.1 DIN-Rail Mounting............... 11 Figure 3.3 WISE-4471 DIN-rail Mounting Installation ....11 Figure 3.4 WISE-4471 DIN-rail Mounting (front)....... 11 Figure 3.5 WISE-4471 DIN-rail Mounting (back) ....... - Page 8 4.2.10 Push Notification................. 38 4.2.11 iSensing MQTT................39 Appendix A iSensing MQTT........43 iSensing MQTT Format for publishing ............ 45 A.1.1 Topic Format: Advantech/MAC_Address/data ......45 A.1.2 Payload Format ................45 A.1.3 Example..................46 iSensing MQTT Format for subscribing ..........48 A.2.1 Topic Format: Advantech/MAC_Address/ctl/doIndex ....
-
Page 9: Chapter 1 Product Overview
Chapter Product Overview... -
Page 10: Series Family And Specifications
ALL OFF No signal/access point module Package Information WISE-4471-S250 1 x WISE-4471-S250 module with internal antenna and terminal connector 1 x plastic wall-mounting bracket 1 x quick startup manual with China RoHS declaration WISE-4471 Series User Manual... -
Page 11: Chapter 2 Product Overview
Chapter Product Overview... -
Page 12: General Specifications
Note! Whether temperature and humidity can be measured will depend on the type of sensor being used. WISE-4471 Series User Manual... -
Page 13: Power
Stop Bits: 1, 2 Parity: None, Odd, Even Flow Control: Auto flow control Signals: DATA+ and DATA- Protection: 15 kV ESD Supported Protocol: Modbus/RTU (Total 32 address by max. 8 instructions) WISE-4471 Series User Manual... -
Page 14: Application Wiring
Application Wiring Figure 2.1 WISE-4471-S250 Digital Output Wiring Diagram Figure 2.2 WISE-4471-S250 Digital Input Wiring Diagram WISE-4471 Series User Manual... -
Page 15: Pin Assignment
Figure 2.3 WISE-4471-S250 RS-485 Wiring Diagram Pin Assignment Figure 2.4 Pin Assignment WISE-4471 Series User Manual... -
Page 16: Block Diagram
Block Diagram Figure 2.5 WISE-4471-S250 Block Diagram WISE-4471 Series User Manual... -
Page 17: Chapter 3 Hardware Installation
Chapter Hardware Installation... -
Page 18: Interface Introduction
Interface Introduction Figure 3.1 WISE-4471 Interface Introduction Mounting Applicable installation methods are briefly described in the following sections. Figure 3.2 WISE-4471 Series Mounting Kit Dimensions WISE-4471 Series User Manual... -
Page 19: Din-Rail Mounting
DIN rail adapter to your module. You can then use the end brackets included in the package in order to keep it from sliding. Figure 3.3 WISE-4471 DIN-rail Mounting Installation Figure 3.4 WISE-4471 DIN-rail Mounting (front) WISE-4471 Series User Manual... -
Page 20: Wall Mounting
Figure 3.5 WISE-4471 DIN-rail Mounting (back) 3.2.2 Wall Mounting The plastic wall-mounting bracket that comes with the module can be used to mount it on a wall, panel, or cabinet. Figure 3.6 WISE-4471 Wall Mounting Installation WISE-4471 Series User Manual... -
Page 21: Pole Mounting
The pole-mounting ring needs to be unlocked with a screw driver before it can be inserted through the module. To mount the module on the pole, tightly lock the pole- mounting ring. Figure 3.8 WISE-4471 Pole Mounting Installation WISE-4471 Series User Manual... -
Page 22: Wiring & Connections
200 mV of peak-to-peak power ripple. The immediate ripple voltage should be maintained between +10 and +50 VDC. The screw terminals labeled "+Vs" and "- Vs" are for the power supply wiring. Figure 3.10 WISE-4471-S250 Power Wiring WISE-4471 Series User Manual... -
Page 23: I/O Units
Use the shortest wire length possible Use wire trays for routing wherever possible Avoid running wires near to high-energy wiring Avoid running input wiring near output wiring Avoid creating sharp bends or kinks in the wires WISE-4471 Series User Manual... - Page 24 WISE-4471 Series User Manual...
-
Page 25: Chapter 4 System Configuration
Chapter System Configuration... -
Page 26: Connection
Internet Explorer 11 or above 4.2.2 Installing WISE Studio The latest version of WISE Studio is available on the Advantech support site: http:// support.advantech.com/. To install the program, download the installation file and execute it locally. WISE-4471 Series User Manual... -
Page 27: A Brief Introduction To Wise Studio
WISE module. Information will be viewable via the embedded web page or you could open web page via browsers. Communication Box In this box, there are several communication interfaces for configuring different WISE modules. The WISE-4471 series uses the USB-serial interface for configuration. Refresh: Pressing this button refreshes the USB-serial interface. ... -
Page 28: Information Page
Modem Manufacturer: Manufacturer of the RF module. IMEI Code: International Mobile Equipment Identity of the current modem. IMSI Code: International Mobile Subscriber Identity of the current SIM card. ICCID Code: Integrate Circuit Card Identity. WISE-4471 Series User Manual... -
Page 29: Connecting To A Cellular Network
Register Status: Registration status with the cellular network operator. Current Service Mode: Network device mode (e.g., LTE CAT-NB1). Signal Strength: Indicates reference signal receiving power (RSRP) of the cel- lular network. IP Address: IP address assigned by the cellular network. WISE-4471 Series User Manual... - Page 30 Auto Write PIN Code: Enables the PIN code to be saved to the WISE module. PIN Code: Configure or modify the PIN code here. Access Point Name (APN): Configure the APN of the cellular network provider. WISE-4471 Series User Manual...
-
Page 31: I/O Status Configuration
Submit at the end of this page will apply the changes. Channel Mask: Each channel can be disabled individually for reducing date traffic during communication. Refresh: Refresh the configuration. WISE-4471 Series User Manual... - Page 32 Reset. The predefined startup value will be the value shown in the Counter value box. When this value is reset, either by pressing Reset on the Status page or by issuing a command, it WISE-4471 Series User Manual...
- Page 33 "logic low" the latch is cleared manually, which will return the logic status to "logic high." The logic status is viewable on the latch status LED dis- play on the DI Status page. Clear the latch by clicking Clear on this page. WISE-4471 Series User Manual...
- Page 34 4.2.6.2 Digital Output Status The values of all digital output channels can be controlled via the status switch, the color of which indicates the current value of the digital output channel. WISE-4471 Series User Manual...
- Page 35 Duty cycle boxes, respectively. Whether a continuous pulse train or finite pulses will be generated is determined by clicking Continuous or Fixed total, respectively. The number of pulses to be generated can be set by entering WISE-4471 Series User Manual...
- Page 36 I/O. These 64 addresses can be coils or registers; coils will be mapped as extension bits of the WISE module, and registers will be mapped as extension words of the WISE module. In the COM1 status tab, the bits and words are shown on indi- vidual pages. WISE-4471 Series User Manual...
- Page 37 Slave Response Timeout: For setting the time for Modbus slaves to reply Delay between Polls: For setting the delay time between each Modbus instruc- tion CRC Check: For disabling the CRC check to ignore Modbus CRC errors WISE-4471 Series User Manual...
- Page 38 Modbus slave devices. The COM port will optimize the scan interval accord- ing your setting. However, the read scan interval may also depend on factors such as the Baud rate, slave device response time, delay between polls, and so WISE-4471 Series User Manual...
- Page 39 After you have changed the rule configurations, logged data in the data logger will be cleared to accommodate the new data structure of the data logger under the new configuration. Note! You can hover your mouse over the table title rows to view tooltips. WISE-4471 Series User Manual...
-
Page 40: System Configuration
WISE module is not able to connect to cellular base station. RF Reset Interval: Decide the time interval in minute to reset the RF module in WISE module when WISE module is not able to connect to cellular base station. WISE-4471 Series User Manual... - Page 41 Time & Date WISE modules have a built-in RTC that allows you to view the current time, set the time zone, and adjust the time by pressing Click Me to read the time from host devices. WISE-4471 Series User Manual...
- Page 42 To update the firmware, go to the Firmware page in System Configuration and click the icon of the file you wish to use in the update. You can find the latest official firm- ware releases on the Advantech support site (http://support.advantech.com/). WISE-4471 Series User Manual...
-
Page 43: Data Logger
4.2.8 Data Logger The WISE-4471 series supports data logging. The I/O status can be logged in and queried from the module. Before you start the log function, please ensure that the RTC inside the WISE module has the correct time. A battery is used to store the time in the RTC but there may be some discrepancy due to the accuracy of the RTC. - Page 44 Logger Configuration On this page, you can enable the local memory storage function. There are separate switches for enabling the logging of I/O data or system data. Simply turn ON the switches to enable logging. WISE-4471 Series User Manual...
- Page 45 Now you can click Query to query the data from local memory. Then, the data will be shown in a chart and table. Click Save to save the data from the WISE module in .Json format, or click Clear to clear all data in local memory. WISE-4471 Series User Manual...
-
Page 46: Diagnostician
The WISE module will push a notification in .Json format to your private server. You can switch the I/O Log or System Log to ON, and the WISE module will then start pushing the latest logged data to the private server. WISE-4471 Series User Manual... -
Page 47: Isensing Mqtt
Then go to “Advanced \ Data Logger \ Data Configuration”, user can decide the update period in “Log Conditions”. The minimum update period is 10 second, so user can configure 100 (0.1 sec) as following figure. WISE-4471 Series User Manual... - Page 48 WISE before start updating data. If the USB port been connected, WISE will stop update data and waiting for configuration. Go to HiveMQ web site http://www.hivemq.com/demos/websocket-client/, enter the Host and Port as following figure, then click “Connect”. WISE-4471 Series User Manual...
- Page 49 Go to “Subscriotions” block, and click “Add New Topic Subscriotion” Enter the topic “Advantech/IMEI_Code/data”, you can find the IMEI code by WISE- Studio, it’s in the page of “Configuraiton \ Cellular \ Cellular Information” After subsctibe the topic of WISE, you can see the data from WISE.
- Page 50 WISE-4471 Series User Manual...
- Page 51 Appendix iSensing MQTT...
-
Page 52: Mqtt
MQTT (message queuing telemetry transport) is a publish/subscribe messaging pro- tocol for constrained Internet of Things devices in low-bandwidth, high-latency, or unreliable networks. Advantech iSensing MQTT is Advantech-defined MQTT topic and payload for iSensing and iConnectivity devices, including WISE-4000 wireless I/ O, ADAM-6000 Ethernet I/O, and B+B Wizard mesh I/O. -
Page 53: Isensing Mqtt Format For Publishing
MQTT Format for publishing A.1.1 Topic Format: Advantech/MAC_Address/data Field Description Advantech Vendor of WISE Series MAC_Address MAC address of WISE Series data Topic for query the data of WISE Series A.1.2 Payload Format Field Abbreviation Description Sequence number that updates each time a sensor reading... -
Page 54: Example
A.1.3 Example Model Name JSON Data Notes The value of di1 and di2 can be: false, true. "s":6, The value of do1 and do2 can be: false, true "t":"2017-11-03T15:06:16Z", "q":192, The value of the sensor in "c":2, engineering units if ai disable WISE-4012E "di1":true,... - Page 55 "s":6, "t":"2017-11-03T15:06:16Z", "q":192, "c":2, "di1":true, WISE-4051 "di2":false, The value of di1 and di2 can (8-DI, 1-RS-485) "di3":true, be: false, true. "di4":false, "di5":true, "di6":false, "di7":true, "di8":false, "s":6, "t":"2017-11-03T15:06:16Z", Temperature and range code "q":192, in the configured engineering WISE-4220-S231 "c":2, units (1-Temperature, 1- "temp1":23.6,...
-
Page 56: Isensing Mqtt Format For Subscribing
"do1" iSensing MQTT Format for subscribing A.2.1 Topic Format: Advantech/MAC_Address/ctl/doIndex These topics are used to control the digital outputs on the sensors that support them. These requests need to be published to the broker handling the Sensor network. -
Page 57: Example
A.2.3 Example Model Name Topic JSON Data Description WISE-4012E Advantech/MAC_Address/ {"v":true} The DO0 value will be (2-DI, 2-DO, 2-AI) ctl/do1 set as true. WISE-4050 Advantech/MAC_Address/ {"v":false} The DO1 value will be (4-DI, 4-DO) ctl/do2 set as false. WISE-4470-S250UA Advantech/MAC_Address/ {"v":false}... - Page 58 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2018...
