- Page 1 ™ Prioris XL and XLDP Server Powergrade Kit Installation Guide Order Number: ER−PC97U−IA. D01 Digital Equipment Corporation...
- Page 2 This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations. Prioris, DEC, DECpc, and the DIGITAL logo are trademarks of Digital Equipment Corporation. Intel and Pentium are registered trademarks of Intel Corporation. MS-DOS is a registered trademark of Microsoft Corporation.
-
Page 3: Table Of Contents
Contents Introduction Tools Needed ....................1 Kit Contents..................... 2 Enable the Onboard VGA Controller..............2 Update Your BIOS Power Down the Server ................... 3 Remove any Video Option Card ............... 3 Check the Jumper Settings ................4 Replace the Panel and Reconnect the Cables ............ 5 Power Up the Server and Update Your BIOS ........... - Page 4 Figures Figure 1 Main Logic Board Jumper Locations ..........4 Figure 2 Removing the CPU Module ............... 7 Figure 3 Installing a Second CPU Chip ............8 Figure 4 Installing the Secondary Cache............9 Figure 5 CPU Module Jumper and Socket Locations........10 Figure 6 Installing the CPU Module .............
-
Page 5: Introduction
Prioris™ ™ XL and XLDP 5166 CPU Powergrade Kit Introduction ™ Thank you for purchasing the Prioris XL or XLDP Powergrade Kit. These Powergrade kits contain all the components and instructions required to upgrade ® your server to a CPU with a speed of either 166 MHz or 200 MHz: Pentium ™... -
Page 6: Kit Contents
Prioris XL and XLDP Server Powergrade Kit Kit Contents Table 1. Kit Contents Kit FR-PC97U- AA CPU Speed 166 MHz 200 MHz ® Pentium CPU chip CPU board w/ 1 CPU CPU board w/ 2 CPUs Main logic board 512KB cache Voltage regulator module BIOS update diskette... -
Page 7: Update Your Bios
Prioris XL and XLDP Server Powergrade Kit 4. Select the Advanced Control Group and enable the Embedded - PCI VGA controller. 5. Select Save and Exit to save this selection. Update Your BIOS A diskette containing the required BIOS (Basic Input-Output System) software is included with the Powergrade kit. -
Page 8: Check The Jumper Settings
Prioris XL and XLDP Server Powergrade Kit Check the Jumper Settings Make sure that the following jumpers are installed: J17 (Figure 1) Onboard VGA Enabled (On) BIOS upgrade Enabled (On) Boot block writable Move jumper from the default pins 1 and 2 to pins 2 and 3. Figure 1. -
Page 9: Replace The Panel And Reconnect The Cables
Prioris XL and XLDP Server Powergrade Kit Replace the Panel and Reconnect the Cables 1. Install the left side panel. The server will not power up with the side panel removed. 2. Connect the cables, the monitor power cord, and the server power cord to the back of the server. -
Page 10: Reset Jumpers On The Main Logic Board
Prioris XL and XLDP Server Powergrade Kit Reset Jumpers on the Main Logic Board 1. As described previously, power down the server. 2. Make sure that the following jumpers, shown in Figure 1, are set to disabled to prevent any unauthorized update to your BIOS: BIOS upgrade Disabled (Off) Boot block update... -
Page 11: Figure 2 Removing The Cpu Module
Prioris XL and XLDP Server Powergrade Kit DEC00243-2 Figure 2. Removing the CPU Module... -
Page 12: Install A Second Cpu Chip (Kits Fr-Pc97U-Aa, -Af Only)
Prioris XL and XLDP Server Powergrade Kit Install a Second CPU Chip (FR-PC97U-AA, -AF Kits Only) ® The CPU module has either one or two Intel Pentium CPUs mounted with heat sinks in socket 5 type ZIF sockets. If you are upgrading the existing CPU module from a single processor to a dual processor (kit FR-PC97U-AA or -AF), install the new Pentium Processor chip as follows: 1. -
Page 13: Install The Secondary Cache
Prioris XL and XLDP Server Powergrade Kit Install the Secondary Cache Move the secondary cache (if present) on the old CPU module to the new CPU module (Kits FR-PC97U-AB, -AG, and -AJ only). Kits FR-PC97U-AA, -AC, -AD, -AE, -AF, and -AH have a new 512 KB cache module. Seat the cache firmly into the socket (Figure 4). -
Page 14: Check The Jumper Settings
Prioris XL and XLDP Server Powergrade Kit Check the Jumper Settings Figure 5 shows the CPU module’s jumper locations. The jumper settings for the bus speed should be 66 MHz. Move the jumpers so they are set correctly for the correct speed of the CPU you are installing. -
Page 15: Install The Voltage Regulator Module
Prioris XL and XLDP Server Powergrade Kit Install the Voltage Regulator Module For kits FR-PC97U-AB, -AC, -AD, -AE, -AF, and -AH only, install the Voltage Regulator module onto the voltage regulator pins on the CPU module, B and C in Figure 5. -
Page 16: Install The New Medallion
Prioris XL and XLDP Server Powergrade Kit Install the New Medallion Install the new medallion (product nameplate) to identify your server to service personnel. To replace the nameplate: 1. Remove the tape on the back to expose the adhesive surface. 2. -
Page 17: Troubleshooting Using The Crisis Recovery Diskette
Prioris XL and XLDP Server Powergrade Kit 4. Select Save and Exit to configure your server for the CPU module. 5. When complete, remove the SCU diskette from drive A and reboot your server. Refer to Chapter 3, “Server Utilities,” in your computer user's guide for any additional information on running the SCU.
