stock
connector
i313-411EX
PCIII USB EX
connectors
ground wire
PCIII USB EX
harness
9
Attach the connectors from the PCIII USB EX
to the stock connector and the throttle body as
shown in Figure D.
10 Attach the ground wire from the PCIII USB EX
to the negative side of the battery as shown in
Figure E.
11 Install the PCIII USB EX in the tail section. If
you are not going to keep the tool kit then you
can lay the PCIII USB EX flat against the inner
fender or you can mount as shown in Figure F.
12 Bolt the fuel tank back down. Install the main
seat and the passenger seat.
13 Insert the cd provided into your computer's
cd-rom drive.
14 Follow the on-screen instructions to install the
PCIII USB EX software.
Visit www.powercommander.com to download
software tutorials and the latest maps.
2003-2006 Suzuki SV 650 - PCIII USB EX - 3
