- Page 1 YS170/YS1700 and HyperTerminal Tech note TN12009 - 1 -...
- Page 2 Overview This tech note describes how to configure the YS170/YS1700 controllers and HyperTerminal to communicate with each other. Follow Slide 3 for YS170 settings. Follow Side 4&5 for YS1700 settings. HyperTerminal settings are identical for both controllers. - 2 -...
- Page 3 YS170 Settings Go to the CONFIG1 screen and set COMM parameters 1. ADRS: Controller Address 2. STBIT: Stop Bits 3. PAR: Parity 4. BPS: Communication Speed Example: ADRS-1, STBIT-1, PAR-NO, BPS-9600. NOTE: These values m ust m atch the settings used in HyperTerm inal.
- Page 4 YS1700 Settings (part 1) Go to the COMM screen and set COMM parameters 1. PSL: Protocol Select (Must be set to YS) 2. ADRS: Controller address 3. STBIT: Stop Bits 4. PAR: Parity 5. DLEN: Data Length 6. BPS: Communication Speed - 4 -...
-
Page 5: Setting Example
YS1700 Settings (part 2) Setting example: PSL: ADRS: STBIT: 1 bit PAR: NONE DLEN: 8 bit BPS: 9600 N OTE: These values m ust m atch the settings used in HyperTerm inal. - 5 -... -
Page 6: Com Port Settings
HyperTerminal Settings COM Port Settings Flow control must be set to Xon/Xoff N OTE: These values m ust m atch the settings on the controller. - 6 -... -
Page 7: Terminal Settings
HyperTerminal Settings Terminal Settings - 7 -... -
Page 8: Ascii Setup
HyperTerminal Settings ASCII Setup - 8 -... - Page 9 Data Commands Data command must be sent to the YS as a string. Construct the command in Notepad or Wordpad and then CUT/PASTE into HyperTerminal. I M M EDI ATELY Follow this by hitting the ENTER key. - 9 -...
- Page 10 Data Commands Example CUT/PASTE DG 01 01 SV1 into HyperTerminal. I M M EDI ATELY Follow this by hitting the ENTER key. The is will retrieve (DG or data get), from controller address 01 (01), one byte of data (01) which is the set point (SV1). - 10 -...
- Page 11 Data Commands Example - 11 -...
- Page 12 Thank you! <Document Number> - 12 - Copyright © Yokogawa Electric Corporation <date/time>...
