Technical
Information
TI 01B08A02-07EN
The contents of this Technical Information are subject to change without notice.
YS1000
Replacement Guide
YS170
YS1700 User Program Conversion
→
Yokogawa Electric Corporation
2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan
TI 01B08A02-07EN
©Copyright June 2014
1st Edition Jun.13, 2014

Advertisement

loading
Need help?

Need help?

Do you have a question about the YS100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YOKOGAWA YS100 Series

Summary of Contents for YOKOGAWA YS100 Series

  • Page 1 Replacement Guide YS170 YS1700 User Program Conversion → TI 01B08A02-07EN The contents of this Technical Information are subject to change without notice. Yokogawa Electric Corporation TI 01B08A02-07EN 2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan ©Copyright June 2014 1st Edition Jun.13, 2014...

  • Page 2: Table Of Contents

    3. Overview of YS100 conversion ..............6 4. YS100 conversion procedure ..............6 5. Precautions ....................16 6. Reference documentation ................17 Revision Information ..................i TI 01B08A02-07EN 1st Edition: June 2014(YK) TI 01B08A02-07EN 2014.06.13 All Rights Reserved. Copyright © 2014, Yokogawa Electric Corporation...

  • Page 3: Introduction

    • Every effort has been made to ensure accuracy in the preparation of this manual. Should any errors or omissions come to your attention, however, please inform Yokogawa Electric’s sales office or sales representative.

  • Page 4: Ys100→Ys1000 Instrument Correspondence Table

    1. YS100→YS1000 Instrument Correspondence Table MODEL Name YS1000 YS170 Programmable Indicating Controller YS1700 YS150 Indicating Controller YS1500 YS135 Manual Setter for SV Setting YS1350 YS136 Manual Setter for MV Setting YS1360 YS131 Indicator with Alarm YS1310 TI 01B08A02-07EN 2014.06.13...

  • Page 5: Old Model Conversion Flow Chart

    2. Old model conversion flow chart Start up YSS1000 Select “YS1000 Configuration Function” in the Select YSS1000 Function window. The Basic window is displayed. Select one of the following tasks from the menu “Convert”. Convert Convert from Convert by reading SLPC user ROM YSS20 file directly from...

  • Page 6: Overview Of Ys100 Conversion

    3. Overview of YS100 conversion Parameters and user programs: Read from the YS100 and convert (1) Convert programs and parameters (2) Download 4. YS100 conversion procedure 4.1 Starting the YSS1000 4.2 YS100 connection and starting the YS100 upload 4.3 Executing the YS100 upload and checking the converted results 4.4 Checking and entering system data 4.5 Saving files 4.6 Comparing programs...
  • Page 7 4.1 Starting the YSS1000 Start the YSS1000 Click the YS1000 Configuration Function 4.2 YS100 connection and starting the YS100 upload Connect the YS100 Start the YS100 upload Menu > Convet > Upload All YS100 TI 01B08A02-07EN 2014.06.13...
  • Page 8 4.3 Executing the YS100 upload and checking the converted results (1) Click STOP and Upload All YS100 (2) Check converted results (a) Correct any errors that are found. Ignore the others and click OK. (b) Parameters expanded from the YS100 become the defaults. 4.4 Checking and entering system data Since it will become the YS1700-100 after conversion, you must enter system data referencing the name plate.
  • Page 9 4.5 Saving files When converting system data, follow the prompts to save files. 4.6 Comparing programs Compare with the YS100 program list (1) Program comments are not retained. TI 01B08A02-07EN 2014.06.13...
  • Page 10 4.7 Checking programs Select Tools > Program check to run a program check. (1) If an error occurs, check the program. 4.7.1 Selecting control functions Care is required when using independent 2-loop control. Ex.: If BSC1 is listed after BSC2, select the control function based on the last BSC1.
  • Page 11 4.8 Checking and entering parameters (part 1) (1) Be sure to reflect the SV value (since upload data is the initialization start value) 4.8 Checking and entering parameters (part 2) Set appropriate default parameters. (1) For the YS170, the Y3 current/voltage selection is specified by jumpers.
  • Page 12 4.9 Downloading on the YS1000 Connect the YS1000. 4.9.1 Execute the download (1) Menu > Communication > Download All Data (2) Click STOP and Execute Download All Data TI 01B08A02-07EN 2014.06.13...
  • Page 13 4.10 Checking operation (debugging programs) Be sure to review the data that was downloaded from the YS100 to the YS1000 and converted, and check operation. 4.10.1 YS1700 operation modes (1) RUN mode: Run user programs. (2) TEST1 mode: Run user programs and simulation programs. (3) TEST2 mode: Run user programs and simulation programs.
  • Page 14 4.10.2 Debug with tuning (1) Menu > Communication > Tuning (2) Click TEST2, execute tuning 4.10.3 Description of the tuning window Trend monitor Register monitor Loop TI 01B08A02-07EN 2014.06.13...
  • Page 15 4.10.4 Debug with tuning (1) Designate all AI, AO, DI, and DO for the register monitor. Drag&Drop 4.10.4 Debug with tuning (1) Set control registers AI and DI as needed. (2) Confirm proper operation. TI 01B08A02-07EN 2014.06.13...

  • Page 16: Precautions

    4.11 Start in RUN mode after debugging Switch from TEST2 mode to RUN mode. 5 Precautions Be sure to review the data that was downloaded from the YS100 to the YS1000 and converted, and check operation. If the program to be converted has multiple differing control commands (BSC1, BSC2, CSC, SSC), the control function of the last step of the program is selected for the control function selection.

  • Page 17: Reference Documentation

    6 Reference documentation Software (user programs) YSS1000 Setting Software/YS1700 Programmable Function • user's manual » (IM 01B08K01-02EN) – 2.13.2 This manual describes how to load user programs and parameters » Connect the YSS1000 PC to the YS100, read the values directly, then convert them to YSS1000 format.
  • Page 18 Blank Page...

  • Page 19: Revision Information

    Revision Information Title : YS1000 Replacement Guide → YS170 YS1700 User Program Conversion Manual number : TI 01B08A02-07EN June 2014/1st Edition Newly published Written by Yokogawa Electric Corporation Published by Yokogawa Electric Corporation 2-9-32 Nakacho, Musashino-shi, Tokyo 180-8750, JAPAN...
