- Page 1 YS1700 – Using 24V DC Loop Power Supply Tech note TN12013 - 1 -...
- Page 2 This tech note will enable you to make use of the built-in 24V DC loop power supply to power up to (2) external transmitters. This will eliminate the need for an external power supply. These transmitters can then be used as inputs into the YS1700 controller. - 2 -...
- Page 3 The resistors should be installed across the input terminals for the desired inputs. In this example 1&2 for input 1 and 5&6 for input 3. Terminal 13 on the YS1700 is the 24V source and should be connected to the positive terminal off each transmitter.
- Page 4 Wiring the Transmitters cont. The negative connection of each transmitter should be connected to the positive terminal of the respective input. In our example, terminal 1 for input 1 and terminal 5 for input 3. - 4 -...
- Page 5 Thank you! <Document Number> - 5 - Copyright © Yokogawa Electric Corporation <date/time>...
