Parts Checklist - BYOC Large Beaver Triangle Instructions Manual

Parts Checklist for the Large Beaver Triangle Kit
Resistors
3 – 150 Ohm (Brown/Green/Black/Black/Brown) or (Brown/Green/Brown/Gold)
1 - 820 Ohm (Gray/Red/Black/Black/Brown) or (Gray/Red/Brown/Gold)
1 - 2k7 (Red/Purple/Black/Brown/Brown) or (Red/Purple/Red/Gold)
1 - 4k7 (Yellow/Purple/Black/Brown/Brown) or (Yellow/Purple/Red/Gold)
2 - 8k2 (Gray/Red/Black/Brown/Brown) or (Gray/Red/Red/Gold)
3 - 12k (Brown/Red/Black/Red/Brown) or (Brown/Red/Orange/Gold)
1 - 15k (Brown/Green/Black/Red/Brown) or (Brown/ Green/Orange/Gold)
3 - 33k (Orange/Orange/Black/Red/Brown) or (Orange/Orange/Orange/Gold)
4 - 100k (Brown/Black/Black/Orange/Brown) or (Brown/Black/Yellow/Gold)
5 - 470k (Yellow/Purple/Black/Orange/Brown) or (Yellow/Purple/Yellow/Gold)
Visit www.byocelectronics.com/resistorcodes.pdf
differentiate resistors.
Capacitors:
3 - 470pF Ceramic Disc capacitor (round yellow or orange with '471' on the body)
1 - 3n9/.0039uF Film cap ("392" on the body)
1 - 8n2/.0082uF Film cap ("822" on the body)
1 - 10n/.01uF Film cap ( "103" on the body)
3 - 47n/ .047uF Film cap ("473" on the body)
6 - 100n/.1uF Film Cap ("104" on the body)
1 - 100uF Aluminum Electrolytic
Visit www.byocelectronics.com/capcodes.pdf
capacitors.
Diodes:
1 - 1N4001
4 - 1N4148 or 1N914
Transistors:
4 - 2N5133
for more information on how to
for more info on how to differentiate
