Weather Guard ITEMIZER 314 Assembly And Installation Instructions

ASSEMBLY AND INSTALLATION INSTRUCTIONS
Models 314 • 316 • 317 • 318 • 326 • 327 • 328
IMPORTANT
BEFORE YOU BEGIN
Read these instructions and
warnings completely before
installation.
Approximate Assembly and
Installation Time:
48 min. per unit (0.8 hrs.)
Depending on Van equipment
installation experience.
BOLT KIT
Bolt Kit #32-0314 is provided with
your Drawer Unit. Check this bolt
kit to be sure the following parts
are included:
Quan. Description
6 1/4-20 x 3/4" Hex Hd. Bolt
4 1/4-20 Blind Fasteners
10 1/4" Flat Washers
6 1/4" Lock Washer, ext. tooth
1 1/4-20 x 2-1/4" Bolt, blk. ox.
1 Installation Tool
4 1/4-20 Nylon Lock Nuts
PARTS LIST
1- Drawer Unit
2- Mounting Brackets
6- Dividers (per drawer section)
ITEMIZER® Aluminum Drawer Units
Figure 1. Aluminum Drawer
Units Shown Stacked
Danger of explosion. Do not use this product for storing or
transporting flammables, explosives, hazardous materials,
or hazardous waste, such as containers of gasoline, solvents,
gun powder, dynamite, propane tanks, acetylene tanks and
cutting torches. This product is only intended and safe for
use in storing and transporting small tools, equipment and
other similar materials. Any modifications made to, or unin-
tended use of this product, could create a hazardous condi-
tion that can cause death, serious personal injury or property
damage.
TOOLS REQUIRED
• Drill with 5/16" & 13/32" drill bits
• 7/16" Open or Box End Wrench (2)
• 9/16" Open or Box End Wrench
DANGER
Part No. 24-0300 REV. E ECN 5315 05/13
1
