Summary of Contents for GSS PAMS 4000

  • Page 1 PAMS 4000...
  • Page 2: Table Of Contents

    o n t e n t s 1 Safety regulations and notes ................ 3 2 General information ..................4 Packing contents ................4 Meaning of the symbols used ............4 Technical data ................4 Description ...................5 Block Diagram ................5 General ..................5 Software query................6 Example application ..............6 Inserting a video signal into a satellite transponder ......6 3 Assembly ....................
  • Page 3: Safety Regulations And Notes

    a f e t y r e g u l a t i o n s a n d n o t e s • Assembly, installation and servicing should be carried out by authorised electricians. • Switch off the operating voltage of the system before beginning with assem- bly or service work or pull out the mains plug.
  • Page 4: General Information

    2.1 P aC k i n g C o n t e n t s 1 Cassette PAMS 4000 1 RF cable 1 BNC cable 1 F cable termi nal...
  • Page 5: Description

    You can find the current operating software for the control unit and the cassette, the software "BE-Flash" and the current assembly instructions on the website "www.mygss.eu". The cassette is intended for use in GSS.modular professional head-end stations. - 5 - PAMS 4000...
  • Page 6: Software Query

    Horizontal input frequency LO = 7300 MHz 10700...12750 MHz corre- sponds to 3400...5450 MHz at output Feed-in switch • The feed-in switch inserts the Sat IF signal of the PAMS 4000 at 950 MHz at the lower end of the vertical plane. SOC 100 •...
  • Page 7 PSU 8-16 Sat IF 950 MHz SOC 100 GL 100 Feed-in switch optical distribution - 7 - PAMS 4000...
  • Page 8: Assembly

    s s e m b l y 3.1 i n s ta l l i n g t h e C a s s e t t e – Ensure the head-end station is mounted so it will not be able to vibrate. Avoid, for example, mounting the head-end station onto a lift shaft or any other wall or floor construction that vibrates in a similar way.
  • Page 9: Emc Regulations

    3.2 emC r e g u l at i o n s To comply with the current EMC regulations, it is necessary to connect the lines leading in and out of the head-end station using cable terminals. When mounting the cassette in a head-end station which is installed in a 19" cabinet, make sure the connections leading in and out for the 19" cabinet are made using cable terminals. The attenuation of shielding of the connection lines for ASI and antenna must meet the requirements for "Class A". CLASS • Insert the required number of cable terminals in the openings provided in the head-end station or in the 19" cabinet. Tighten the nuts on the cable terminals until the teeth on the lock washer have penetrated the exterior coating and a good connection is made between the housing and cable terminals.
  • Page 10: Cassette Overview

    • Connect the ASI output of an PADE 4000 to the ASI input of the PAMS 4000. • Connect RF output of the PAMS 4000 via an F feedthrough from the head-end station (see page 8). • Connect the head-end station to the mains. - 10 -...
  • Page 11: The Control Panel At A Glance

    C o n t r o l P a n e l g l a n C e 4.1 m e n u i t e m s Programme the cassette using the buttons on the control unit of the head-end station.
  • Page 12: Programming

    r o g r a m m i n g 5.3 P ro g r a m m i n g Pro C e d u r e Ein / On Bedienhinweise Operating Hints BE–Remote V 45 "blättert" Menüs vorwärts. scrolls forward through the menu.
  • Page 13: Notes On Level Setting

    5.2 n ot es l e v e l s e t t i n g In order to prevent interference, you must adjust the output level of the cassette to the satellite IF spectrum of the receiving system. 5.3 P r o g r a m m i n g t h e C a s s e t t e...
  • Page 14: Output Parameter, Level

    The "Output parameter" – "OUTPUT" menu is activated. u t P u t Pa r a m e t e r l e v e l In this menu you adjust the output level of the modulator and you have access to the submenus for the modulator configuration.
  • Page 15: Output Symbol Rate, Spectral Position, Code Rate (Fec)

    (feC) u t P u t s ym b o l r at e P e C t r a l P os i t i o n C o d e r at e In this menu you can set the symbol rate, the Spectral position and the code rate of the output signal.
  • Page 16: Station Filter

    • Press the button. —> The "Station filter" – "INPUT ASI" menu is activated. tat i o n f i lt e r The default setting for the station filter is "ALL". In this menu you define the stations received to be transmitted. If stations are activated the output symbol rate increases.
  • Page 17 —> The display shows e.g.: Box 4 TV + 01/10 Das Erste Meaning of the indicators in the example: "Box 4" Slot 4 "TV" TV channel type " + " The currently selected station is switched on. "01/10" The 1st of 10 stations is being displayed. "Das Erste" Station name Further possible terms displayed: "RA" Radio channel type For radio stations, the background of the screen of the connected TV or test receiver is darkened.
  • Page 18: Output Data Rate

    u t P u t data r at e This menu shows the maximum possible output data rate and the current need- ed output data rate in MBit/s. 36.0: The current needed output data rate. DATARATE 38.0: Maximum output data rate (dependent on OVER 36.0 / 38.0 the settings of symbol rate and the FEC).
  • Page 19: Factory Reset

    aC to ry r es e t In this menu you can reset all settings to the factory defaults. FACTORY FACTORY ▶ Defaults => STORE => M • Press the button. —> The factory defaults are invoked. —> By pressing the button, you will be returned to the menu item "Output parameter, level"...
  • Page 20: Final Procedures

    i n a l P r o C e d u r e s After installing the head-end station, upgrading accessories or installing cas- settes it is necessary to tighten all cable connections, cable terminals and cover screws in order to maintain compliance with current EMC regulations securely. • Securely tighten the cable connections using an appropriate open-ended spanner. • Measure the output levels of the other cassettes and tune them to a uniform output level using the appropriate level controls or software dependent on the head-end station used.
  • Page 21 Declaration of CE conformity GSS Grundig Systems GmbH • Beuthener Straße 43 • D-90471 Nuremberg Phone: +49 (0) 911 / 633 240 0 • Fax: +49 (0) 911 / 633 240 98 www.gss.de/en • info@gss.de CLASS CLASS Service: Phone: +49 (0) 911/ 633 240 90 • service@gss.de Alterations reserved.
