- Page 1 Head-End Modulator FM IP to 12xFM PMDF 1000 CLASS Phone: +49 (0) 911 / 703 8877 Grundig SAT Systems GmbH Fax: +49 (0) 911 / 703 9210 Beuthener Strasse 43 E-mail: info@gss.de D-90471 Nuremberg Internet: http://www.gss.de...
-
Page 2: Table Of Contents
Channel selection ................ 23 Language selection ..............24 Frequency deviation adjustment ............ 24 Kind of transmission ..............25 RDS ................... 25 Output level ..................26 Factory reset ..................26 Saving settings ................. 27 6 Final procedures ....................28 - 2 - PMDF 1000... -
Page 3: Safety Regulations And Notes
European Council from January 27, 2003 which addresses old electronic and electrical devices, such devices must be disposed of at a designated collection facility. At the end of its service life, please take your device to one of these public collection facilities for proper disposal. - 3 - PMDF 1000... -
Page 4: General Information
C o n t e n t s 1 Cassette PMDF 1000 1 LAN cable 1 Brief assembly instructions... -
Page 5: Technical Data
Pilot signal .................. 19 kHz Preemphasis ...................50 μs Connections LAN input ................1 RJ45 socket HF output ..............1 IEC socket, female Connection strip ................10-pin for supply voltages and control circuits RS-232 socket: ........serial interface for software update - 5 - PMDF 1000... -
Page 6: Description
To operate this cassette the software version of the control unit must be “V 44” or higher. You can find the current operating software for the control unit and the cassette, the software “BE-Flash” and the current assembly instructions on the website “www.gss.de”. The cassette is designed for use in head-end stations of the profi line. - 6 -... -
Page 7: Software Query
If necessary, you can activate the indication of the software version of the control unit manually: • Press any two keys on the control unit of the head-end station simultaneously until the display goes dark and the software version, e.g. “V 44” appears. Cassette After activating the cassette the software version of the cassette is displayed (see page 14). - 7 - PMDF 1000... -
Page 8: Assembly
– Before installing or changing a cassette unplug the power cable from the mains power socket. • Remove the fastening screws of an unoccupied slot from the bracket of the head-end station. • Insert the cassette in this slot and push it into the housing. • Align the cassette and apply slight pressure to connect it to the connections of the board and the HF bus bar. • Fasten the cassette with the screws - 8 - PMDF 1000... -
Page 9: Emc Regulations
19” cabinet. Tighten the nuts on the cable terminals until the teeth on the lock washer have penetrated the exterior coating and a good connection is made between the hous- ing and cable terminals. - 9 - PMDF 1000... -
Page 10: Cassette Overview
9-pin D-SUB socket “RS 232” using a PC or notebook and the software “BE-Flash”. You can find the current operating software on the website “www.gss.de”. o n n e C t i n g t h e C a s s e t t e • Plug the LAN input cable into the LAN input socket. -
Page 11: The Control Panel At A Glance
The key pad on the head-end station is used to scroll through the menus: scrolls forward through the menus. select parameters in the menus. set values, initiate actions. selects sub-menus. scrolls backward through the menus. saves all entries. - 11 - PMDF 1000... -
Page 12: Programming
0 … 65535 Seite 13 ◀ ▶ Bx 4 INPUT Bx 4 MODE/PORT ▶ => 1234 UDP / RTP, 0 … 65535 ◀ ▶ Bx 4 IP-INPUT 227. Bx 4 SERVICES ▶ => CLEAR ALL - 12 - PMDF 1000... - Page 13 Bx 4 LEVEL 0 dB 0 … - 10 dB Seite 12 auf Werkseinstellung Bx 4 FACTORY Bx 4 FACTORY zurücksetzen und speichern ▶ reset to factory defaults Defaults => STORE => M and store - 13 - PMDF 1000...
-
Page 14: Programming The Cassette
—> The display shows e.g. the menu "Box 4 IP-FM": "Box 4" stands for slot 4, "IP-FM" type of cassette "V 1" software version of the cassette • Press the button. —> The “Setting the Ethernet parameters” – “ETHERNET” menu is activated. - 14 - PMDF 1000... -
Page 15: Setting The Ethernet Parameters
IP address displayed to be set and use to set the IP address wished. • Press the button. —> The “Setting the address range” – “IP-MASK” menu is activated. - 15 - PMDF 1000... -
Page 16: Setting The Address Range
IP address displayed to be set and use to set the IP address wished. • Press the button. —> The “Setting the UDP port” – “UDP-PORT” menu is activated. - 16 - PMDF 1000... -
Page 17: Setting The Udp Port
Via this menu you have access to the submenus for the input parameters. Bx 4 INPUT => • Press the button. —> The “Selecting the transmission protocol, setting the port number” – “MODE / PORT” menu is activated. —> With the button the input parameter settings are skipped. The menu “Delete programme locations” – “SERVICES” is activated. - 17 - PMDF 1000... -
Page 18: Selecting The Transmission Protocol
• Using the buttons set the port number wished. • Press the button. —> The “Setting the IP address of the input transport stream” – “IP-INPUT” menu is activated. - 18 - PMDF 1000... -
Page 19: Setting The Ip Address Of The Input Transport Stream
Signal present No signal • Press the button. —> You will be returned to the menu item “Setting the input parameters” – “INPUT”. • Press the button. —> The menu “Delete programme locations” – “SERVICES” is activated. - 19 - PMDF 1000... -
Page 20: Delete Programme Locations
—> All programme locations are deleted, the stored FM frequencies will be remain. As long as no radio station is assigned to a programme location, the transmitter is switched off. —> A "Factory Reset" resets to the programme locations preset in the factory. • Press the button. —> The “Output parameters” – “FM 01” menu is activated. - 20 - PMDF 1000... -
Page 21: Programme Locations
The output parameter settings are to be done for each of the 12 programme locations. The programme location is displayed in the upper left corner – e.g. FM 01 means programme location 01. FM 01 - 21 - PMDF 1000... - Page 22 => auto FM 03 RDS-NAME FM 12…01 => auto FM 02 RDS-NAME => auto FM 01 RDS-NAME Bayern 1 => auto FM 01…12 FM 12…01 • Press the button. —> Submenu “Output frequency” – “FREQ” is activated. - 22 - PMDF 1000...
-
Page 23: Output Frequency
ASI) is transmitted via the corresponding programme location. FM 01 RA 001/091 Bayern 1 Meaning of the indicators: “FM 01” Programme location FM 01 “RA” Radio channel “001/091” Channel 1 of 91 “Bayern 1” Programme name of channel 1. - 23 - PMDF 1000... -
Page 24: Language Selection
C y d e v i at i o n a dj u s tm e n t In this submenu you can adjust the deviation. This has effects for the volume. FM 01 VOLUME 0.0 dB <=>C • With buttons adjust the frequency deviation in 0.1 dB steps. - 24 - PMDF 1000... -
Page 25: Kind Of Transmission
• Press to set the respective digit of the name. —> Via the "auto" function you can adopt the RDS Programme Service Name automatically from the channel name of the transponder. - 25 - PMDF 1000... -
Page 26: Output Level
P u t l e v e l In this menu the output level can be adjusted (0 … -10 dB). Bx 4 LEVEL 0 dB • With the buttons adjust the output level wished. • Press the button. —> The “Factory reset” – “FACTORY” main menu is activated. - 26 - PMDF 1000... -
Page 27: Saving Settings
“Input parameters” – “INPUT” invoking the factory defaults (page 15). av i n g s e t t i n gs • Press the button. —> Back to “Selecting the cassette” (page 14). —> The settings are saved. - 27 - PMDF 1000... -
Page 28: Final Procedures
After installing the head-end station, upgrading accessories or installing cas- settes it is necessary to tighten all cable connections, cable terminals and cover screws in order to maintain compliance with current EMC regulations securely. • Securely tighten the cable bolted connections using an appropriate open- ended spanner. • Mount the front cover (see assembly instructions of the head-end station). - 28 - PMDF 1000... -
Page 29: Pmdf
Declaration of CE conformity - 29 - PMDF 1000... - Page 30 Service: Phone: +49 (0) 911 / 703 2221 Fax: +49 (0) 911 / 703 2326 Email: service@gss.de Alterations reserved. Technical data E. & O.E. © by GSS GmbH V1/14122010...
