- Page 1 I/R Thermometer Gun 12:1 800103 INSTRUCTION MANUAL SPER SCIENTIFIC...
-
Page 2: Table Of Contents
Contents Page 1. Introduction ........... 2 2. Safety Information ......... 3 3. Display And Button Locations ....... 4-5 4. Distance to Spot ........... 5 5. Measuring Procedures ......... 6 6. Battery Replacement ........6 7. Cleaning ............7 8. Specifications ..........7-8 9. -
Page 3: Safety Information
SAFETY INFORMATION Read the following safety information carefully before attempting to operate or service the IR Gun. Only qualified technicians should perform repairs. • DO NOT submerge the IR Gun in water. • Protect the IR Gun from water, shock, dust, and extreme environments. -
Page 4: Display And Button Locations
3. DISPLAY AND BUTTON LOCATIONS 1. Laser Guide 2. IR Sensor 3. Trigger 4. °C/°F Selector 5. Laser On/Off Selector 6. Battery 7. Battery Cover - 4 -... -
Page 5: Distance To Spot
SCAN °C HOLD °F 193. 8. Low Battery Indicator 11. °C & °F 9. Laser Guide On/Off 12. Hold 10. Scan 13. Temperature Reading 4. Distance-to-Spot The distance-to-spot ratio is 12:1. As the distance from the object increases, the spot size of the area measured by the gun also increases. -
Page 6: Measuring Procedures
5. MEASURING PROCEDURES See page 4-5 for display and button locations. For best results, allow the thermometer to adjust to the ambient temperature for 30 minutes before use. For accurate readings, the IR lens must be clean (pg 7). • Slide the Laser ON/OFF Selector (5) to turn the Laser Guide (1) on or off. -
Page 7: Cleaning
7. CLEANING To obtain accurate readings, the lens must be clean. Clean the lens with compressed air, soft brush, or a moist cotton swab. Do not use solvents on the lens. Clean the case with mild soap on a cloth or sponge. 8. -
Page 8: Warranty
781~1000MHz at 3V/m, the unit may not meet its stated accuracy. 9. WARRANTY Sper Scientific warrants this product against defects in materials and workmanship for a period of 5 years from the date of purchase, and agrees to repair or replace any defective unit without charge.
