Front Door Fitting; Additional Adapter Board; Cable; Power Supply - Assa Abloy Effeff Technilock L4 Series Installation And Fitting Instructions

®
only for Technilock L4
without follower
Order supplementary
board
Order connection cable
Accessories

Front door fitting

Long escutcheon protection rating 2 (only for version with follower, 60 mm backset) N44274109200000
Long escutcheon protection rating 4 (only for version with follower, 60 mm backset) N44274109400000
Short escutcheon

Additional adapter board

The additional adapter board shown in the chapter "Electrical connection", page 34, Fig. 7 for an
expandable electrical connection is not included in the scope of delivery of the Technilock
additional board is only suitable for Technilock
ordered separately:
effeff – Supplementary board for Technilock

Cable

The cable type specified in the chapter "Power supply", page 35 is not included in the scope of delivery
of the Technilock ® L4. The cable can be ordered separately:
effeff – Connection cable for Technilock

Power supply

The mains adapter with adjustable output voltage specified in the chapter "Power supply", page 35 is
not included in the scope of delivery of the Technilock
effeff – Mains adapter for Technilock
Property
Input voltage
Output voltage, adjustable
Output current
(Current limiting on the output current with auto-
matic restarting)
Ambient temperature range
Housing
® L4 without follower. The supplementary board can be
® L4
® L4
®
L4. The mains adapter can be ordered separately:
® L4
Characteristic
90 V – 260 V AC
24 V DC, stabilised
4 A
–20°C – +40°C
Synthetic material with screw connection terminals
844S6B4 – – – – – – – –
® L4. The
844L4ZBP1 – – – – 00
844ZBKAB01 – – – 00
effeff 1003–24–4 – – – – 10
EN
39
