Removal; Stowage; Storage Of Victory Step (If Installed); Storage - Lippert Components SOLIDSTEP 2.0 Master Owner's Manual

Removal

To remove the installed handrail from the Victory Step, unscrew the top and bottom fastening knobs (Fig. 7D)
then slide the handrail tube out of the brackets.

Stowage

To stow the handrail, align the holes in the handrail with the holes on the front face of the Victory Step
(Fig. 6). Screw the fastening knobs into the holes in the handrail, then hand-tighten until the handrail is
secured to the Victory Step.

Storage of Victory Step (if installed)

The Victory Step can also be stored using the accessory Garage Kit (sold separately), which includes brackets
(Fig. 8A), clevis pins (Fig. 8B) and hairpin cotter pins (Fig. 8C).
NOTE: The garage storage brackets are NOT designed to hang the Victory Step on the wall while
suspended above the floor. Suspending the Victory Step above the floor could lead to wall damage.
The garage storage brackets are designed to hold the Victory Step in a fixed position for travel
where the feet of the step are resting on the floor and the step is leaning slightly against the garage
storage brackets, which are attached to the wall.

Storage

1. Ensure that both feet on the Victory Step are set to the same height adjustment, then set the step so
both feet are on the ground about 3 to 4 inches away from the wall (Fig. 9).
Rev: 11.08.19
Fig. 8
A
C
B
Fig. 9
Page 16
CCD-0001573-11
