Summary of Contents for Lippert Components SOLIDSTEP 2.0
- Page 1 Master Owner's Manual Steps...
- Page 2 User notice The Table of Contents is an interactive field. Click on the desired section to be taken immediately to the corresponding page.
-
Page 3: Table Of Contents
Master Owner's Manual The Master Owner's Manual is intended to provide information on Lippert Components Inc.'s most widely- used products. Products described in the Master Owner's Manual may not be on every trailer. The trailer may also have products not included in this manual. All manual information is subject to change without notice. -
Page 4: Manual Steps
MANUAL STEPS STEPS Introduction This document details the operation and maintenance of manual steps. Safety The “WARNING” symbol above is a sign that an installation procedure has a safety risk involved and may cause death or serious injury if not performed safely and within the parameters set forth in this manual. -
Page 5: Step Operation
Step Operation Unfolding Steps Pull out on the top lip of the step vertically stored (Fig. 1A). Pull up and out on the back of step resting on the second step (Fig 2A). Unfold bottom step (Fig. 3). Folding Steps Pull up on bottom step and fold over the second step (Fig. -
Page 6: Solidstep
SOLIDSTEP ® STEPS Introduction The SolidStep® 2.0 is a trailer entry step assembly mounted to the side of any trailer, providing an ease of entry, regardless of level ground. Safety Information Failure to follow the instructions provided in this manual may result in death, serious personal injury, product or property damage, or voiding of the component warranty. -
Page 7: Operation
Operation Release Steps Disengage transport lock (Fig. 1). Firmly grasp and pull out the vertically stored SolidStep and firmly rest it on the ground. Adjust leg extensions as needed, see Leg Extension Adjustment section. Fig. 1 Transport Lock Storage of Steps Retract leg extensions, if desired. - Page 8 Moving parts can pinch, crush or cut. Keep clear and use caution. To retract the inner leg: D. Remove the quick release clevis pin from the outer and inner legs. Retract the inner leg. Reinstall the quick release clevis pin into the outer leg slot and into the closest inner leg hole that intersects with the outer leg's slot.
-
Page 9: Solidstep
SOLIDSTEP ® STEPS System Information The SolidStep® 3.0 is a trailer entry step assembly mounted to the side of any trailer, providing an ease of entry, regardless of level ground. NOTE: Step identification tags are located under one of the step extrusions, typically the top full step. Safety information Failure to follow the instructions provided in this manual may result in death, serious personal injury, product or property damage or voiding of the component warranty. -
Page 10: Operation
Operation Release Steps Disengage transport lock (Fig. 1). Firmly grasp and pull out the vertically stored SolidStep and firmly rest it on the ground. Adjust leg extensions as needed, see Leg Extension Adjustment section. Fig. 1 Transport Lock Storage of Steps Retract leg extensions, if desired. - Page 11 Step Identification Top Step Full Step Lock Assembly Plunger Bolt Page 11 Rev: 11.08.19 CCD-0001573-11...
-
Page 12: Victory Step
VICTORY STEP™ STEPS Introduction The Victory Step™ is an entry step assembly that can be mounted to the side of any patio opening to provide ease of entry . The suggested deck height range should be between 23"-35" for a triple step and 30"-45" for a quad step. -
Page 13: Step Operation
Step Operation Step Deployment Align the step latches at the top of the Victory Step with the installed footman loops (Fig. 1), then lower until both step latches click into place around the footman loops. Lower the Victory Step to the ground. Fig. -
Page 14: Height Adjustment
Height Adjustment To adjust the foot height, lift the step and remove the fastening pin that secures the foot to the step tube. Align the tube (Fig. 3A) to the desired holes then reinsert the fastening pin (Fig. 3B). Repeat on the other side, if necessary. -
Page 15: Handrail (If Equipped)
Handrail (if equipped) Installation To remove the handrail (Fig. 6A) for installation, unscrew the fastening knobs (Fig. 6B). The knobs will be used for installation of the handrail. Fig. 6 To install the handrail, align the short end of the handrail tube with the top bracket (Fig. 7A) on the left side of the Victory Step and the long end of the handrail tube (Fig. -
Page 16: Removal
Removal To remove the installed handrail from the Victory Step, unscrew the top and bottom fastening knobs (Fig. 7D) then slide the handrail tube out of the brackets. Stowage To stow the handrail, align the holes in the handrail with the holes on the front face of the Victory Step (Fig. -
Page 17: Removal
Lean the top of the Victory Step towards the garage storage brackets then lower until both step latches click into place around the clevis pins (Fig. 8B) on the garage storage brackets. Make sure both step latches are secure around the clevis pins (Fig. 10) and both feet are on the floor. Fig.10 Removal To remove the Victory Step, push the step latches levers forward (Fig. - Page 18 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty.
