- Page 1 Level Up Travel Trailer ® OWNER'S MANUAL...
-
Page 2: Table Of Contents
Mechanical portions of the system are replaceable. Contact Lippert Components, Inc. to obtain replacement parts. Additional information about this product can be obtained from lci1.com/support or by downloading the free myLCI app. -
Page 3: Safety
Follow the trailer manufacturer's recommendations for lifting and supporting the unit. Failure to do so may result in death or serious injury. Lippert Components Inc. recommends that a trained professional be employed to change the tires or perform other service on the trailer. Attempts to change the tires or perform other service while trailer is supported solely by the LCI Level Up automatic leveling system could result in death, serious personal injury or severe product or property damage. -
Page 4: Prior To Operation
Prior to Operation The leveling system shall only be operated under the following conditions: Make sure to park the trailer on solid, level ground. Make sure all jack landing locations are cleared of debris and obstructions and also free of depressions. When parking the trailer on extremely soft surfaces, utilize load distribution pads under each jack. -
Page 5: Touchpad Diagram
Touchpad Diagram Fig. 1 Fig. 1 PN 234802 - Black PN 421484 - Gray LCD Touchpad Features Callout Description UP Arrow - Scrolls up through the menu on LCD. DOWN Arrow - Scrolls down through the menu on LCD. ENTER - Activates modes and procedures indicated on LCD. RETRACT - Places leveling system into retract mode while in manual mode only. -
Page 6: Hitch Recognition
Hitch Recognition Turn on touchpad. Press the LEFT and RIGHT jack buttons simultaneously (Fig. 1H and 1I). The front of the trailer will raise to the height where the auto-level sequence was started. NOTE: If the auto-level sequence was started with the front of the trailer in a below-level condition, the hitch recognition will not function and the LCD will display Feature Disabled. -
Page 7: Maintenance
Type “A” Automatic Transmission Fluid (ATF) is utilized and will work. ATF with Dexron III® or Mercon 5® or a blend of both is recommended by Lippert Components, Inc. In colder temperatures (less than 10° F) the jacks may extend and retract slowly due to the fluid’s molecular nature. -
Page 8: Troubleshooting
Troubleshooting Error Display In LCD Screen NOTE: To clear an Error Code, press the ENTER button (Fig. 1C). If the error remains, the Error Code will appear again. Error Codes LCD Message What's Happening? What Should Be Done? Check and secure controller Controller not properly secured. -
Page 9: Manual Override
Manual Override The LCI Level Up Automatic Leveling System can be manually operated with an electric drill. In the event of electrical or system failure, this manual method of extending and retracting the jacks can be used. See the instructions below. NOTE: Unhook the power unit motor from the power source prior to attempting the manual override procedure. - Page 10 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
