- Page 1 Hydraulic Motorized Leveling (82-L0356) OWNER'S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Safety Operation Operating Conditions Selecting A Site Leveling Procedures Jack Retract Procedures Troubleshooting Automatic Safety Shutoff Feature Drive Away Protection System Troubleshooting Table Maintenance Fluid Recommendation Preventative Maintenance Introduction NOTE: Information for this document was based on Power Gear document 82-L0356, with a revision date of June 2003. -
Page 3: Safety
LCI limited warranty. The use of the Lippert Components, Inc. Hydraulic Motorized Leveling to support the coach for any reason other than which it is intended is prohibited by the Lippert Limited Warranty. The system is designed as a leveling system only and should not be used for any reason to provide service under the coach, e.g. -
Page 4: Operation
Operation Operating Conditions Do not use the leveling jacks to support the coach while under the coach or changing tires. The hydraulic leveling system is designed only as a leveling system. It is recommended that a trained professional change tires. Attempts to change tires while supporting the coach with the hydraulic system could result in death or serious personal injury, severe product and/or property damage. -
Page 5: Jack Retract Procedures
Fig. 1 Callout Description ON/OFF - Turns leveling system on and off. The LED will be on if the system is operational. If flashing with the WAIT LED, it signals the coach transmission must be placed in park. RETRACT JACKS - Retracts all jacks. FRONT JACKS - Extends both front jacks. -
Page 6: Troubleshooting
Automatic transmission fluid (ATF) with Dexron®III or Mercon®V or a blend of both is recommended by Lippert Components, Inc. For a list of approved fluid specifications, see TI-188. To obtain this Technical Information sheet online, go to documents/ti-188-hydraulic-operation-fluid-recommendation. Look for TI- 188: Hydraulic Operation Fluid Recommendation within the listings. -
Page 7: Preventative Maintenance
Preventative Maintenance Check fluid level every month. Inspect and clean hydraulic pump electrical connections every 12 months. Remove dirt and road debris from jacks as needed. Change fluid every 36 months. A. Fill the reservoir with the jacks in the fully retracted position. B. - Page 8 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
