UTX Series
Portable U-Trough Grain Auger
Assembly Manual
This manual applies to:
AGI Westfield UTX (44)
AGI UTX (44)
AGI Hutchinson UTX (44)
AGI Mayrath UTX (44)
AGI GrainMaxx UTX (44)
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
LOOKING FOR PARTS?
Check out our online
Parts Catalog!
Part Number: 31084 R8
Revised: October 2024
Original Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UTX Series and is the answer not in the manual?

Questions and answers

Related Manuals for AGI UTX Series

Summary of Contents for AGI UTX Series

  • Page 1 UTX Series Portable U-Trough Grain Auger Assembly Manual This manual applies to: AGI Westfield UTX (44) AGI UTX (44) AGI Hutchinson UTX (44) AGI Mayrath UTX (44) AGI GrainMaxx UTX (44) LOOKING FOR PARTS? Check out our online Parts Catalog! Read this manual before using product.
  • Page 2 New in this Manual The following changes have been made in this revision of the manual: Description Section Updated the wheel assembly instructions. Section 4.15 – Attach the Upper Frame to the Axle on page 32 Updated the fuel tanks. Section 4.20.1 –...

  • Page 3: Table Of Contents

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER CONTENTS 1. Introduction ............................5 2. Safety............................... 6 2.1 Safety Alert Symbol and Signal Words..................6 2.2 General Safety Information....................... 6 2.3 Rotating Flighting Safety ......................7 2.4 Rotating Parts Safety......................... 7 2.5 Hydraulic Winch Safety ......................7 2.6 Drives and Lockout Safety......................
  • Page 4 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.21.1 Install the Gearbox Pulley ..................46 4.21.2 Install the Idler Assembly..................47 4.21.3 Install the Guard Assembly ..................47 4.21.4 Install the Belt ......................48 4.21.5 Install the Clutch Guard Assembly ................. 49 4.21.6 Install the Gearbox Pulley Cover................

  • Page 5: Introduction

    Before assembling, please read this manual. Familiarize yourself with the process and the necessary precautions for efficient and safe assembly of this AGI Portable U-Trough Grain Auger. Everyone present at the assembly site is required to be familiar with all safety precautions.

  • Page 6: Safety

    • Follow a health and safety program for your worksite. Contact your local occupational health and safety organization for information. • Contact your local representative or AGI if you need assistance or additional information. • Always follow applicable local codes and regulations.

  • Page 7: Rotating Flighting Safety

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY 2.3. Rotating Flighting Safety • KEEP AWAY from rotating flighting. • DO NOT remove or modify flighting guards, doors, or covers. Keep in good working order. Have replaced if damaged. • DO NOT operate the auger without all guards, doors, and covers in place.

  • Page 8: Drives And Lockout Safety

    2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2.6. Drives and Lockout Safety Inspect the power source(s) before using and know how to shut down in an emergency. Whenever you service or adjust your equipment, make sure you shut down the power source and unplug or remove the key (as applicable) to prevent inadvertent start-up and hazardous energy release.

  • Page 9: Hydraulic Power Safety

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY 2.6.2 Hydraulic Power Safety Power Source • Refer to the rules and regulations applicable to the power source operating the hydraulic system. • Do not connect or disconnect hydraulic lines while system is under pressure.

  • Page 10: Tire Safety

    2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2.7. Tire Safety Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion that may result in serious injury or death. • DO NOT attempt to mount a tire unless you have the proper equipment and experience to do the job.

  • Page 11: Personal Protective Equipment

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY 2.9. Personal Protective Equipment The following Personal Protective Equipment (PPE) should be worn when assembling the equipment. Safety Glasses • Wear safety glasses at all times to protect eyes from debris.

  • Page 12: Safety Decals

    2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2.11. Safety Decals • Keep safety decals clean and legible at all times. • Replace safety decals that are missing or have become illegible. See decal location figures that follow. • Replaced parts must display the same decal(s) as the original part.
  • Page 13 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY Figure 2. Safety Decal Locations P1513136 20803 17113 20807 20813 20811 19960 20817 Figure 3. Safety Decal Locations (HD Hydraulic Steering) 20806 28128 31084 R8...
  • Page 14 2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Figure 4. Safety Decal Locations (Hydraulic Winch) 20810 20806 31084 R8...
  • Page 15 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY Table 1. Safety Decals Part Number Description 20817 DANGER ELECTROCUTION HAZARD To prevent death or serious injury: • When operating or moving, keep equipment away from overhead power lines and devices.
  • Page 16 2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Table 1 Safety Decals (continued) Part Number Description 20803 (inside) WARNING MISSING GUARD HAZARD To prevent serious injury or death, shut off power and reattach guard before operating machine. 20804 WARNING...
  • Page 17 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY Table 1 Safety Decals (continued) Part Number Description 20807 WARNING To prevent serious injury or death: • Read and understand the manual before assembling, operating, or maintaining the equipment. • Only trained personnel may assemble, operate, or maintain the equipment.
  • Page 18 2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Table 1 Safety Decals (continued) Part Number Description 20811 WARNING UPENDING HAZARD To prevent death or serious injury: • Anchor intake end and/or support discharge end to prevent upending. • Intake end must always have downward weight.
  • Page 19 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY Table 1 Safety Decals (continued) Part Number Description P1513136 WARNING CONTENTS MAY BE UNDER PRESSURE As part of the fuel vapour retention system, it is normal for your tank to expand from internal pressure. Use the vent screw to relieve pressure and before refueling.

  • Page 20: Features

    3. FEATURES UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 3. Features discharge & upper chain drive intake hopper & hopper cloth shaft guarding hydraulic winch hydraulic HD SP kit belt idler pulley guarding belt tension adjustment collapsible hopper cloth control...

  • Page 21: Assembly

    Take pictures of shipments prior to, or just after, unloading if there are any damages. Report missing or damaged parts immediately to ensure that proper credit is received from AGI or your representative, and to ensure that any missing parts can be shipped quickly to avoid holding up the assembly process.

  • Page 22: Hydraulic Fittings And Bolt Tightening

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.4. Hydraulic Fittings and Bolt Tightening Remember the following basic considerations when tightening hydraulic fittings and bolts: • Tighten all fasteners to the torque specified in Section 6.1 – Bolt Torque on page 82.

  • Page 23: Assemble The U-Trough & Flighting

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.6. Assemble the U-Trough & Flighting flight connector shaft lock nut, 7/16" bolt, 7/16" x 3" bolt, 7/16" x 1-1/4" Fixing a Twisted U-Trough It is important to minimize twist in the trough during assembly. Excessive twist could cause the intake hopper or spout to not sit level relative to the ground.

  • Page 24: Install The Track Stops

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.7. Install the Track Stops Assembly Note: • Slide track shoe onto track before attaching upper track stop. track stop lock nut, 7/16" track shoe bolt, 7/16" x 1" track washer, 7/16"...

  • Page 25: Assemble The Driveshaft

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.8. Assemble the Driveshaft lower driveshaft driveline bracket assembly driveshaft connector bolt, 7/16" x 1-1/4" square key, 1/4" x 1-1/2" flat washer, 7/16" set screw, 3/8" x 3/8" lock nut, 7/16"...
  • Page 26 4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER ~2-¾" gearbox mount bracket driveshaft guard guard hanger bracket bolt, 7/16" x 1-1/4" flat washer, 7/16" bolt, 3/8" x 1" lock nut, 7/16" lock nut, 3/8" 31084 R8...

  • Page 27: Install The Spout

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.9. Install the Spout spout bolt, 7/16" x 1-3/4" lock nut, 7/16" 31084 R8...

  • Page 28: Add Grease To The Head Cover

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.10. Add Grease to the Head Cover 1. Remove the head cover from the discharge end. 2. Fill the head cover half full of grease. 3. Lubricate the chain. 4. Re-install the head cover.

  • Page 29: Install The Hopper Assembly

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.11. Install the Hopper Assembly hopper assembly lock nut, 7/16" bolt, 7/16" x 1-1/4" lock collar, 1-1/4" 31084 R8...

  • Page 30: Attach The Lower Frame To The U-Trough

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.12. Attach the Lower Frame to the U-Trough Assembly Note: • Ensure that the pulley shim guard is centered on the lower arm bolt plates. spacer lower frame pulley shim guard bolt, 3/8"...

  • Page 31: Attach The Lower Frame To The Axle

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.13. Attach the Lower Frame to the Axle Assembly Notes: • Loosely install the lower frame to the axle assembly. • Loosely install all the lower support frame hardware. • Tighten all hardware once all of the hardware has been placed.

  • Page 32: Attach The Upper Frame To The Trough

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.14. Attach the Upper Frame to the Trough upper frame arm bolt, 3/4" x 6-1/2" track shoe (installed in a previous section) lock nut, 3/4" 4.15. Attach the Upper Frame to the Axle...
  • Page 33 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Assembly Note: • Remove the stand from the intake end of the auger trough and raise the discharge end with a block and tackle or a front end loader and a strong sling or chain. Height should be sufficient so the frame can be easily attached to the axle.

  • Page 34: Install The Over-Center Drive

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.16. Install the Over-Center Drive 1. Position the axle cap of the over-center drive assembly squarely on the axle tube. 2. With the pinion gear flush with the ring gear, bolt the axle cap to the axle tube using four carriage bolts and lock nuts.

  • Page 35: Adjust The Pinion Gear

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.17. Adjust the Pinion Gear Failure to ensure proper gear meshing will result in gear damage. The pinion gear should mesh with the ring gear to provide maximum tooth contact. Insufficient meshing •...

  • Page 36: Install The Reversible Gearbox

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.18. Install the Reversible Gearbox Assembly Notes: • Check the gearbox oil level; gearbox should be half full. Use only EP90 lube oil and fill to HALF FULL only. • The ends of the gearbox shaft and the driveshaft should be flush with the inside of the chain coupler sprockets.
  • Page 37 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Assembly Notes: • Ensure the reversible gearbox components do not interfere with any other auger components. • The detent lever must be in the same position as the gearbox shifter. Ensure the lock pin is engaged with the bracket.

  • Page 38: Install The Motor Mount

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.19. Install the Motor Mount engine slider assembly cotter pin, 3/16" x 1-3/4" motor pivot pin Assembly Note: • Ensure leveller tube is through slots in the engine slider assembly before attaching to leveller tube mount brackets.

  • Page 39: Install The Gas Drive

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.20. Install the Gas Drive 4.20.1 Install the Battery and Fuel Tank Fuel Tank Assembly Notes: • Route the fuel line between the heat shield and gas tank. • EPA Fuel Tank: Torque the brass fitting to 10 ft·lbs. Use teflon tape.

  • Page 40: Install The Engine Slider Mount Bracket

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Battery U-bolt, 1/4" x 9-3/4" x 8-1/4" lock nut, 1/4" battery 4.20.2 Install the Engine Slider Mount Bracket engine slider mount bracket bolt, 7/16" x 1-1/4" lock nut, 7/16" 31084 R8...

  • Page 41: Install The Hydraulic Pump

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.20.3 Install the Hydraulic Pump hydraulic pump assembly lock nut, 7/16" bolt, 7/16" x 1-1/4" steel fitting, 3/4" HB x 10 MORB steel fitting, 8 MORB x 1/2" FNPSM 31084 R8...

  • Page 42: Install The Electric Clutch

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.20.4 Install the Electric Clutch Assembly Note: • Apply anti-seize to the engine shaft where the electric clutch will slide on. gas engine motor square key, 1/4" x 3" electric clutch, triple bolt, 7/16"...

  • Page 43: Install The Cold Weather Kit

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.20.5 Install the Cold Weather Kit 1. Attach the muffler to the engine with bolts. 2. Remove the debris filter cap from the intake air filter port. Save the hose clamp for later use.
  • Page 44 4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER intake air filter port air filter cap hose clamp clamp intake air filter drain port intake air filter mount ducting bolts (supplied with muffler kit) muffler shield port muffler 31084 R8...

  • Page 45: Install The Motor

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.20.6 Install the Motor Assembly Notes: 1-1/4" • Place the motor so that the gap between the face of the electric clutch and the inside face of the guard attach bracket is 1-1/4".

  • Page 46: Install The Drive Components

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.21. Install the Drive Components 4.21.1 Install the Gearbox Pulley Assembly Notes: • Ensure that the hub set screws are toward the outside. • The distance between the face of the gearbox shaft and the outside hub should be 3/8".

  • Page 47: Install The Idler Assembly

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.21.2 Install the Idler Assembly Assembly Notes: • Use a level/square to ensure the idler assembly is mounted straight. • The slots in the main plate can be used to adjust the tilt of the pulleys.

  • Page 48: Install The Belt

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.21.4 Install the Belt Pump Belt Assembly Note: • Rotate the pump handle clockwise to apply tension to the pump belt and pull down the handle to lock the belt in place.

  • Page 49: Install The Clutch Guard Assembly

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.21.5 Install the Clutch Guard Assembly Installing the Clutch Guard Assembly Note: • Slip clutch guard over the electric clutch and slide into the guard assembly. clutch guard bolt, 3/8" x 1"...
  • Page 50 4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Installing the Manual Belt Engage Guide Rod manual belt engage guide rod bolt, 1/2" x 1-3/4" manual belt engage mount bracket lock nut, 1/2" Installing the Manual Belt Engage Handle Assembly manual belt engage threaded rod bolt, 1/2"...

  • Page 51: Install The Gearbox Pulley Cover

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.21.6 Install the Gearbox Pulley Cover pulley guard cover whiz nut, 3/8" bolt, 3/8" x 5" 4.21.7 Tension the Belt TIGHTEN BELT LOOSEN BELT Assembly Note: • Use the two hex nuts to apply tension to the drive belt prior to closing the guard cover.

  • Page 52: Wire The Electric Clutch

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.22. Wire the Electric Clutch 1. Remove (cut off) the clutch harness connector that includes a connection clip on one side. 2. Prepare the cut end for connection by trimming harness jacket and wire...

  • Page 53: Install The Lift Cable

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.23. Install the Lift Cable 1. Attach the cable to the cable attach rod welded to the bottom of the track by wrapping it around the rod and doubling-back about 7" (18 cm) of cable.

  • Page 54: Install The Hydraulic Winch And Connect The Lift Cable

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.24. Install the Hydraulic Winch and Connect the Lift Cable Hydraulic Winch hydraulic winch assembly lock nut, 3/8" steel fitting, 90, 6 MNPT x 6 FNPSM flat washer, 3/8" 31084 R8...
  • Page 55 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Connect the Lift Cable winch cable 1. Pull cable to the winch. 2. Wrap the cable over and around the winch drum. Important Make sure there is a minimum of three wraps of cable on the winch drum when the auger is in transport position.

  • Page 56: Install The Hopper Canvas Handle

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.25. Install the Hopper Canvas Handle hopper canvas handle lock nut, 7/16" rubber handle grip bolt, 3/8" x 1-1/2" bolt, 7/16" x 1" lock nut, 3/8" flat washer, 7/16" 31084 R8...

  • Page 57: Install The Hopper Cable

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.26. Install the Hopper Cable hopper cable flat washer, 3/8" bolt, 3/8" x 1-1/2" lock nut, 3/8" 31084 R8...

  • Page 58: Install The Hydraulic Oil Tank

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.27. Install the Hydraulic Oil Tank 7 " 28 " Assembly Notes: • Place the first hydraulic tank mount 7" from the end of the tube. • Place the second hydraulic tank mount 28" from the end of the tube.
  • Page 59 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Assembly Note: • Ensure the cap is located on the raised side. hydraulic tank lock nut, 1/4" square U-bolt, 1/4" x 7-1/4" x 7-5/8" 31084 R8...

  • Page 60: Install The Hydraulic Filter

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.28. Install the Hydraulic Filter Assembly Note: • The hydraulic hoses MUST be installed to ensure that the oil flows to the tank, in the same direction as the arrow on the filter head.

  • Page 61: Install The Hydraulic Manifold

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.29. Install the Hydraulic Manifold hydraulic manifold lock washer, 5/16" bolt, 5/16" x 3/4" 4.30. Install the Undercarriage Connecting the SP Reach Arms to the Mover Assembly AWD SP reach arm lock nut, 1/2"...
  • Page 62 4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Connecting the SP Reach Arms to the Axle Assembly Note: • This connection must rotate—do not overtighten. AWD SP reach arm lock nut, 3/4" axle bolt, 3/4" x 2" Installing the SP Reach Arm Tie Braces Assembly Note: •...
  • Page 63 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Installing the Slider Assembly onto the Tube and Mover Assembly Assembly Note: • These joints must pivot—do not overtighten. AWD mover slider assembly bolt, 5/8" x 2" bolt, 3/4" x 2"...
  • Page 64 4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Installing the Mover Controls Assembly Assembly Note: • This connection must rotate—do not overtighten. mover controls assembly lock nut, 3/4" controls tower bolt, 3/4" x 5-1/2" Installing the Bent Steel Hydraulic Lines Assembly Notes: •...
  • Page 65 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Installing the Straight Hydraulic Steel Lines onto the Axle Assembly Note: • Install the clamp bracket with the bend tab pointing towards the axle. hydraulic manifold hydraulic tube clamp bracket hydraulic steel line, straight bolt, 3/8"...

  • Page 66: Install The Hydraulic Adapters

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.31. Install the Hydraulic Adapters Installing Adapters at the Valve steel fitting, 45, 8 MORB x 1/2 FNPSM hydraulic valve steel fitting, 45, 6 MORB x 6 MJIC 31084 R8...
  • Page 67 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Installing Adapters at the Hydraulic Motors hydraulic motor steel fitting, 90, 8 MNPT x 6 FNPSM 31084 R8...
  • Page 68 4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Installing Adapters at the Hydraulic Winch hydraulic winch steel fitting, 90, 6 MNPT x 6 FNPSM 31084 R8...
  • Page 69 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Installing Adapters at the Steering Cylinder mover steering cylinder steel elbow, 90, 6 MORB x 3/8 NPSM 31084 R8...

  • Page 70: Attach The Transport Chain

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.32. Attach the Transport Chain Assembly Notes: • If necessary, the transport chain assembly can be shortened. – Remove mid link from chain. – Attach mid link to the appropriate chain link.

  • Page 71: Attach The Hydraulic Hoses

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.33. Attach the Hydraulic Hoses Hydraulic Hose Routing D2/K2 D1/K1 D2/K2 C2/J2 C1/J1 C2/J2 D1/K1 C1/J1 Hydraulic Components hydraulic valve oil filter hydraulic winch drive motor hydraulic cylinder, slider hydraulic cylinder, steering...
  • Page 72 4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Hydraulic Hoses Length Item Hose Ends A1/A2 3/8" MNPT x #6 FJIC 3/8" x 248" #6 FJIC x #6 FJIC B1/B2 3/8" x 60" #6 FJIC x #6 MJIC C1/C2 3/8" x 54"...
  • Page 73 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Hydraulic Hoses A1 & A2 Hydraulic Hoses B1/B2, F1/F2, I1/I2, P, T & H I1/I2 B1/B2 F1/F2 31084 R8...
  • Page 74 4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Hydraulic Hose G Note Route hose G under the engine slider assembly along the lower frame. Hydraulic Hoses E1 & E2 Hydraulic Hoses C1/C2 & D1/D2 (from Valve) 31084 R8...
  • Page 75 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY Hydraulic Hoses J1 & J2 Hydraulic Hoses K1 & K2 31084 R8...
  • Page 76 4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Hydraulic Steering Valve 31084 R8...

  • Page 77: Install Electronic Throttle Controls

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.34. Install Electronic Throttle Controls Attaching the Throttle Controls throttle controls lock nut, 5/16" bolt, 5/16" x 3/4" Attaching the Bottom Cover throttle controls bottom cover lock nut, 5/16" bolt, 5/16" x 3/4"...

  • Page 78: Harness Routing

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.34.1 Harness Routing Attaching the Ground Wire Ring Terminal Routing the Harness 31084 R8...

  • Page 79: Install The Manual Holder

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. ASSEMBLY 4.35. Install the Manual Holder manual holder mount lock nut, 3/8" manual holder bolt, 1/4" x 3/4" square U-bolt, 3/8" x 3-1/16" x 4" flat washer, 1/4" flat washer, 3/8" lock nut, 1/4"...

  • Page 80: Install The Work Lights

    4. ASSEMBLY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.37. Install the Work Lights 1. Install the discharge-area flood lamp to the track stop with a bolt, washer, and lock nut, then plug the wiring harness connector into the flood lamp connector. Ensure that the connectors are fully engaged.

  • Page 81: Specifications

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 5. SPECIFICATIONS 5. Specifications Specification Trough Width 11" (279 mm) CAPACITIES Unloading Rate 7000–9000 Bu/Hr TRANSPORT DIMENSIONS Length 45'6" (13.9 m) 8' (2.4 m) Width Height 10'6" (3.2 m) DISCHARGE CLEARANCE DIMENSIONS 9'6" (2.9 m) 18'1"...

  • Page 82: Appendix

    6. APPENDIX UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 6. Appendix 6.1. Bolt Torque Table 2 gives the correct torque values for various hardware. Tighten all bolts to the torque specified, unless otherwise noted. Check tightness periodically, using Table 2 as a guide.

  • Page 83: Fittings Torque Values

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 6. APPENDIX 6.2. Fittings Torque Values These specifications are for carbon steel. With Zinc plating always lubricate threads and seals. For stainless steel, use the high value of the torque range of steel. For brass, use 70% of the torque value of steel. For mixed metals, use the torque of the lower of the two metals.
  • Page 84 6. APPENDIX UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Table 5 Stud End O-Ring Boss (ORB) SAE (U/UF) – Carbon Steel (continued) Max N-m Tube Size Thread UNF-2A Max ft-lbs 22-24 29-33 9/16" - 18 40-43 49-53 3/4" - 16...

  • Page 85: Agi Limited Warranty

    7. AGI Limited Warranty This warranty relates to AGI Augers (the “Product”) sold by AGI, (referred to herein as the “Seller”) and applies only to the first user of the Product (meaning a purchaser directly from the Seller or from an authorized dealer or distributor of the Product, referred to herein as the “Buyer”).
  • Page 86 AGI is a leading provider of equipment solutions for agriculture bulk commodities including seed, fertilizer, grain, and feed systems with a growing platform in providing equipment and solutions for food processing facilities. AGI has manufacturing facilities in Canada, the United States, the United Kingdom, Brazil, South Africa, India and Italy and distributes its products globally.
