15.

MB2 controller: Time programs

The MB2 program controller permits programming time programs with real-time reference. It offers 25
program memory positions with up to 100 program sections each.
For each program section you can enter a temperature set-point, a pressure set-point, section duration,
type of temperature and pressure transition (ramp or step), the switchings states of the special controller
functions and the tolerance ranges.
If the safety controller has been set to "limit" mode, check the setting of the safety controller
when changing the temperature set-point, (chap. 11.2).
Programming remains saved in case of a power failure or after turning off the unit.
Main menu > Programs> Time program
Path:

15.1 Starting an existing time program

In Normal display press the Program start icon to access the "Program start" menu.
• In the field "Program type" select the setting "Time program".
• In the field "Program" select the desired program.
• Select the field "Program start" and enter the desired program start time in the "Program start" entry
menu. Press the Confirm icon. The program delay time until program start begins.
The program end is adapted automatically depending on the entered program duration.
After completing the settings, press the Confirm icon to take over the entries and exit the menu. The
program starts running.
If instead you press the Close icon to exit the menu without taking over the entries, the program will not
start.
VD (E3.1) 03/2020
"Program start" menu
Normal display. Information on the bottom of the
screen indicates the currently running program and the
time already passed. The grey bar shows how much
time of the whole time is elapsed. If program duration
has been set to infinite, the grey bar is not displayed.
page 101/173
