- Page 1 BAC2405 BATTERY CHARGER USER MANUAL SMARTGEN (ZHENGZHOU) TECHNOLOGY CO., LTD.
- Page 2 BAC2405 BATTERY CHARGER USER MANUAL SUMMARY Fit with up-to-date power supply device, float charger BAC2405 is specially designed for meet the charging characteristics of the lead-acid engine starter batteries and can be used for long-term float charging of 24V lead-acid batteries.
- Page 3 BAC2405 BATTERY CHARGER USER MANUAL SPECIFICATION Items Contents Parameters Nominal AC Voltage AC (100~240)V Max. AC Voltage AC (90~280)V AC Frequency 50Hz/60Hz Max. Active Power 164W Input Max. Current 2.5A Characteristics AC 110V AC 220V Max. Efficiency No-load Power <3W Consumption 27.6V...
- Page 4 BAC2405 BATTERY CHARGER USER MANUAL VOLTAGE/CURRENT REGULATION 6.1 VOLTAGE REGULATION If adjust voltage on-site, battery need to be disconnected with battery charger, and then adjust the voltage potentiometer (VOLT) to the appropriate value while measuring the charger output voltage. 6.2 CURRENT REGULATION After connecting output port to the storage battery, measuring charging current under 25.0V charging...
- Page 5 BAC2405 BATTERY CHARGER USER MANUAL 7.2 BAC2405 TROUBLESHOOTING 7.2.1 FAULT DIAGNOSIS Output terminal of battery charger short circuit or battery reverse connection may blow the charger output fuse. In that case, after connecting AC power supply, charger green LED lights up but output terminal without voltage outputting, and then remove the output fuse tube to visually observe whether fuse is blown or not, if condition permit, multimeter can be used to measure the fuse status.
