3+2 Drawer Chest
Assembly Instructions
002 xx 9413
- Please keep for future reference
Dimensions
Width - 68.5cm
Depth - 38.8cm
Height - 89.5cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 09/04/19
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for JD Williams Taylor 3+2 Drawer Chest
Summary of Contents for JD Williams Taylor 3+2 Drawer Chest
- Page 1 3+2 Drawer Chest Assembly Instructions 002 xx 9413 - Please keep for future reference Dimensions Width - 68.5cm Depth - 38.8cm Height - 89.5cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 622xx6082 Left drawer side x 5 (35.0x15.0cm) 0834 (68.5x38.8cm) 623xx6082 Right drawer side x 5 (35.0x15.0cm) 0435 Plinth x 2 (65.1x7.6cm) 0835 0836 Left End Panel...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 0834 0841 0842 0835 0837 0836 0435 622xx6082 624xx7034 624xx7020 622xx6082 0840 0575 0838 0667 623xx6082 622xx6082 624xx7034 623xx6082 Drawers x 3 0840 0839 623xx6082... - Page 6 Assembly Instructions Step 1 Fitting dowels to top panel. Insert 6 metal dowels into the top panel 0834 0834 Note: Tighten metal dowels up fully against the panel. Do not over-tighten. Step 2 Fitting cams to the plinth and rail panels. Insert 4 cams into the plinth panel...
- Page 7 Assembly Instructions Step 4 Diagram 1 Attaching the left bracket to the left end. Using 2 screws secure the bracket the left end panel 0835 as shown in diagram 1. Diagram 2 Use 1 screw secure the front of the bracket.
- Page 8 Assembly Instructions Step 6 Fitting dowels to the lh, rh & large drawer fronts. Insert 4 metal dowels 0838 into the the drawer 0838 fronts . Repeat on 0839 and the large 0667 drawers Step 7 Insert small cams 622xx6082 into left Right hand side and right...
- Page 9 Assembly Instructions : Locate the metal dowels (already inserted) in the drawer front into the small cams in the left and right hand drawer sides. Ensure drawer sides are 623xx6082 pressed against drawer front. Turn cams 180 degrees to 622xx6082 lock.
- Page 10 Assembly Instructions Step 9 Diagram 1 Attaching cams and left bracket to the divider. Using 2 screws secure the bracket the divider panel 0841 as shown in diagram 1. Use 1 screw Diagram 2 0841 secure the front of the bracket.
- Page 11 Assembly Instructions Step 12 Connect left end to the plinth and rail panels Two people are recommended for this stage 0835 Connect the dowels in the left end 0835 to the cams in the plinth panels 0435 0837 and rail Turn cams 180 degrees 0837 to lock.
- Page 12 Assembly Instructions Step 14 Connect the top panel 0834 and secure the divider. Connect the dowels in 0841 0834 the top panel 0835 the left end 0835 right end 0836 0837 Turn cams 180 degrees to lock. 0836 0841 Secure the divider 0837 to the rail panel using 1 screw...
- Page 13 Assembly Instructions Step 16 Secure back panel. Use the panel pin guide when locating the panel pins. This will hold the panel pins vertical and ensure the correct distance from the edge. Step 17 Add stability blocks. Slide the thin point of the stability blocks between the back panel 0842...
- Page 14 Assembly Instructions Step 18 Fit the drawers. Stand the unit up. Tilt the drawers as shown and slide onto the runner brackets. 0838 0839...
- Page 15 Assembly Instructions Step 19 Fixing to wall We recommend that this unit is fixed to a suitable wall to prevent possible overbalancing. We have included a fixing bracket for this. No fixing screws are provided as they will need to suit the wall type, and the length of screw will depend on the distance from the...
- Page 16 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
