QWIK MPO Termination Instructions
General
®
The CommScope
QWIK MPO Termination Kit and Connector Kit, with the Splicer Kit (ordered separately)
facilitate the proper termination of CommScope
connectors onto 3mm round 12 fiber loose-tube cordage is accomplished by following this method.
Ordering information is listed below:
Material ID
760163931
SFC-12MX-8SP-30-GR
760163949
SFC-12MP-8SP-30-GR
760163956
MFC-12MX-5SP-30-AQ
760163964
MFC-12MP-5SP-30-AQ
760163972
MFC-12MX-6SP-30-BG
760163980
MFC-12MP-6SP-30-BG
Parts List – Connector Kit includes:
Quantity
Description
1
Boot/furcation tube
1
Spring
1
Ferrule subassembly with cap
1
Outer housing
1
Spiral wrap
1
Protection sleeve
Material ID
760188698
Parts List – Qwik MPO Termination Kit includes:
Quantity
Description
Assembly platform with fiber arrangement tool (ribbonizer)
1
Fiber stub connector holder
1
Fiber ribbonizing glue
1
www.commscope.com
®
Connector Kits
Part No.
SMAPC male, green 3mm round
SMAPC female, green 3mm round
MM OM3 male, aqua 3mm round
MM OM3 female, aqua 3mm round
MM OM1 male, beige 3mm round
MM OM1 female, beige 3mm round
Qwik MPO Termination Kit
Part No.
460143027
QWIK MPO termination kit
(Qwik MPO Termination Kit Parts List is continued next page)
© 2014 CommScope, Inc. All rights reserved
QWIK MPO connectors. Field termination of 12F MPO
Description
Description
Instruction Sheet 860532050
Issue 4, July 2014
Page 1 of 13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CommScope QWIK MPO Series
Summary of Contents for CommScope QWIK MPO Series
- Page 1 Parts List – Qwik MPO Termination Kit includes: Quantity Description Assembly platform with fiber arrangement tool (ribbonizer) Fiber stub connector holder Fiber ribbonizing glue (Qwik MPO Termination Kit Parts List is continued next page) © 2014 CommScope, Inc. All rights reserved Page 1 of 13...
-
Page 2: How To Contact Us
Yarn shears Fine tip marker QWIK MPO termination instruction sheet Separately Orderable Items Note: Splicer Kit is not offered by CommScope and must be obtained through Sumitomo or other authorized sources. Splicer Kit Sumitomo Mass Fusion Splicer Type-Q-101-M12 kit (Recommended) or Sumitomo Mass Fusion Splicer Type-66-M12 TuffCat kit Parts List –Splicer Kit includes:... -
Page 3: Step 1 - Prepare The Cable
860532050 Issue 4, July 2014 Pre-Termination Set-Up and Preparation Recommendations 1. Ensure work area is a clean surface with adequate lighting. 2. The following repair and splicer operation should be performed by an individual with adequate and appropriate training. - Page 4 860532050 www.commscope.com Instruction Sheet Note: When making a repair, cut cable back to remove any damaged fibers. 3. Make a slit from the mark to the end of the cable with the jacket remover tool. 4. Prepare to ribbonize 1.97 in (50mm) of fiber. Fold jacket and strengthening yarn back as shown and secure in position with clip or adhesive tape.
- Page 5 CommScope’s cable assemblies. Important: CommScope trunks follow method B fiber polarity. 1. For Commscope cable assemblies with the connector keys facing up, channel 1 on End A of the cable assembly always goes to channel 12 on End B of cable assembly.
- Page 6 860532050 www.commscope.com Instruction Sheet Table 1 can be used as a guide to the orientation of the ribbonized cable when being spliced onto the QWIK MPO ferrule in the splicer: Cable Gender Blue Fiber Position Type (when placed in splicer)
- Page 7 860532050 Issue 4, July 2014 Note: Because CommScope cable assemblies follow method B polarity, verify that the ribbonized fiber is in the proper orientation for method B polarity when placed in the fiberclip holder. Ensure that the ribbonized fiber is placed in the fiber clip holder such that the blue fiber orientation is consistent with Table 1 for whichever cable type and gender you are terminating.
- Page 8 860532050 www.commscope.com Instruction Sheet Step 5 – Align Ribbonized Fibers and Splice the Connector 1. Turn on the mass fusion splicer. Splicer display shows several fiber type options. Select the correct fiber type and arc test using proper fibers. Select splice condition of SM12 or MM12, depending on fiber type to be spliced.
- Page 9 860532050 Issue 4, July 2014 IMPORTANT: Do not pull the fibers during splicing. 9. After the splice is complete, estimated results will display: green for passing, red for failing. Open the door and remove the assembly from the fiber clamps.
- Page 10 860532050 www.commscope.com Instruction Sheet Step 6 – Assemble the Connector 1. Remove the tape or clip holding the cable jacket and the strengthening yarn. 2. Unscrew the rear housing from the boot assembly. 3. Slide the rear housing up to the ferrule, pulling the jacket and strengthening yarn through the rear housing.
- Page 11 860532050 Issue 4, July 2014 6. Insert assembled connector into the MPO adapter on the platform and secure the cable jacket with the clamp on the opposite end of the platform. Keep jacket and fibers taut to minimize any slack in the fiber/cable while mounted in the assembly platform.
-
Page 12: Appendix A: Fiber Ribbon Splicing With Method B Polarity Onto Qwik Mpo Connector (Female-Female Trunk Cables)
860532050 www.commscope.com Instruction Sheet Appendix A: Fiber Ribbon Splicing with Method B Polarity onto QWIK MPO Connector (Female-female Trunk Cables) Ferrule/ Ribbon Orientation when Ribbon Fiber placed in Splicer Color Blue Orange Ribbonized fiber / Ferrule Stub Green Brown Slate... -
Page 13: Appendix B: Ferrule / Ribbon Orientation When Inserted Into Mpo Housing (Female-Female Trunk Cables)
860532050 Issue 4, July 2014 Appendix B: Ferrule / Ribbon Orientation When Inserted into MPO Housing (Female-female Trunk Cables) Ribbon / Ferrule Orientation when Housing Ribbon Fiber inserted into MPO Housing Orientation View Color and Channel Blue Orange Ribbonized fiber / Ferrule stub...
