Peer-to-peer service mode

Advertisement

LMR Service Examples
AP-LMR2000 LMR Gateway
IP-PBX
(x)
(y)
IP Network Participant
p
p
PTT Server
SIP
IP Network
LMR Gateway
Radio I/F
(z)
(a)
(a)
(b)
(b)
LMR Network Participant
PTT Participant
www.addpac.com
Interconnection LMR systems to IP network
Interconnection LMR systems to IP network
through AddPac RoIP solution.
1.
The Terminal(x) originate a PTT conference.
2.
IP-PBX send invitation message to all participant.
3.
The Terminal(x) presses the 'floor button' to talk.
4.
The Terminal(x) send a 'floor-request' message.
5.
IP-PBX and PTT servers control media-relay.
6.
The Terminal(x) releases the 'floor button'.
7.
The Terminal(x) send a 'release-request' message.
8.
8
IP-PBX and PTT servers control media-relay.
IP PBX and PTT servers control media relay
9.
Any LMR Terminal(a~d) presses the 'floor button' to talk.
10.
LMR Gateway send a 'floor-request' message.
11.
IP-PBX and PTT servers control media-relay.
12
12.
The Terminal(a) releases the floor button .
The Terminal(a) releases the 'floor button'
13.
LMR Gateway send a 'release-request' message.
14.
IP-PBX and PTT servers control media-relay.
repeater
repeater
(c)
(c)
(d)
(d)
RTP (floor)
RTP(Participant)
Radio(Participant)
Radio(Participant)
10
