Table 14 shows the location of the pins of the HyperTransport Socket, J3. The middle pins (121-132) are not
shown though since they are all connected to ground (GND).
More information about these connectors can be found in "Web Resources" on page 14.
Odd Pin Name
VDD33
VDD33
VDDLDT
GND
TCK
TMS
TDI
TDO
TRST_L
SCL
SDA
LDT_RESET_L
LDT_PWROK
GND
LDT_RX_CTLn
LDT_RX_CTLp
GND
LDT_RX_CADn7
LDT_RX_CADp7
GND
GND
LDT_RX_CADn6
LDT_RX_CADp6
GND
LDT_RX_CADn5
LDT_RX_CADp5
GND
LDT_RX_CADn4
Document 91125E-UM100-R
S
OCKET

Table 14: Pinout For Hypertransport Socket (J3)

Odd Pin Even Pin
Number Number
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40
41 42
43 44
45 46
47 48
49 50
51 52
53 54
55 56
B roadc om C or por ati on
(J3)
Even Pin Name
VDD33
VDD33
VDDLDT
GND
CLK100
GND
RDY
OE_L
WR_L
CS_L0
CS_L1
INT
RESET_L
GND
LDT_TX_CADp0
LDT_TX_CADn0
GND
LDT_TX_CADp1
LDT_TX_CADn1
GND
GND
LDT_TX_CADp2
LDT_TX_CADn2
GND
LDT_TX_CADp3
LDT_TX_CADn3
GND
LDT_TX_CLKp
