Trango Systems High Density Mesh System User Manual page 38

HD Mesh Node
Sensitivity
Security
Modulation
techniques
RF power output
Wi-FiR
* The system will use a maximum of 350 Watts. However, if any of the other 3 outlets are in use, the
consumption will increase by the device's power consumption.
† Fan turns ON at 120° F (49° C) and OFF at 90° F (32° C).
Heat plate turns ON at -40° F (-40° C) and OFF at 60° F (15° C).
Trango Broadband Wireless — High Density MESH
Wireless Board
802.11a: -88 dBm @ 6 Mbps, -71 dBm @ 54 Mbps
802.11b: -95 dBm @ 1 Mbps, -90 dBm @ 11 Mbps
802.11g: -90 dBm @ 6 Mbps, -74 dBm @ 54 Mbps
Hardware 40 bit & 108 bit WEP.
Hardware AES-CCM
802.11b/g: DSSS (DBSP, DQPSK, CCK) OFDM
for data rate > 20 Mbps
802.11a: OFDM (BPSK, QPSK, 10-QAM,
64-QAM
18 dBm @ 2.4 GHz
17 dBm @ 5.8 GHz
WECA Compliant, FCC Part 15 (USA)
