HD Mesh Node

Section 3 Basic Configuration via Web Browser

This section describes a few basic concepts, as well as how to configure basic settings using the
Browser (HTTP) Interface. This section is written to address only the most basic steps. It is highly
recommended that you visit and read Mikrotik's website to gain an understanding of all important
configuration parameters.
In this section you will learn the following:
•
Configure an IP address
•
Configure Firewall
•
Configure DHCP Server
•
Upgrading the RouterOS
The initial page once you have login is the Interface page. Clicking on the IP address will allow you to
assign the interface an IP address. Clicking on the Interface will allow you to change the interface name from
the standard naming convention. (Figure G)

Web Browser Interface page

Figure 7
Trango Broadband Wireless — High Density MESH
Clicking on the
Name will open a
page to change the
Name.
Clicking on the IP
address will bring up
the port
configuration page.
Clicking the graph
link will open a
MRTG graph of the
interface
page 14
