Porter CENTER-STRUT Assembly, Installation & Maintenance Instructions

Height adjustment units electric and manual operation for use on no. 500 and 600 line backstops
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A
SSEMBLY
C
Patent No's. 5,279,496; 6,056,654; 6,537,162. Other patents pending.
2011 PORTER ATHLETIC EQUIPMENT COMPANY. ALL RIGHTS RESERVED.
, I
NSTALLATION
-S
ENTER
TRUT
E
LECTRIC AND
For Use on No. 500 and 600 Line Backstops
SAVE THESE INSTRUCTIONS FOR FUTURE USE
& M
AINTENANCE
H
A
EIGHT
M
I
NSTRUCTIONS
DJUSTMENT
ANUAL OPERATION
PREV.
NEXT
RAISE
LOWER
SPORTSONIC II
Gymnasium
Control System
GYMNASIUM CONTROL CENTER
Back-
1
2
3
stops
Curtains
4
5
6
MISC.
7
8
9
UP
DOWN
0
AUX.
On
Off
POWR-TOUCH
SYSTEM
U
NITS
INST 00472
10-14-2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CENTER-STRUT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Porter CENTER-STRUT

Summary of Contents for Porter CENTER-STRUT

  • Page 1 SPORTSONIC II Gymnasium Control System GYMNASIUM CONTROL CENTER Back- stops Curtains MISC. DOWN AUX. POWR-TOUCH SYSTEM Patent No's. 5,279,496; 6,056,654; 6,537,162. Other patents pending. SAVE THESE INSTRUCTIONS FOR FUTURE USE INST 00472 2011 PORTER ATHLETIC EQUIPMENT COMPANY. ALL RIGHTS RESERVED. 10-14-2011...
