Operation - Porter CENTER-STRUT Assembly, Installation & Maintenance Instructions

PARTS LIST – SPORTSONIC II OPERATION
C
Nylon spacer
(2) located
between fan
backboard
support and
backboard
No. 500 LINE MAST WITH FAN BACKBOARD
PARTS LIST - No. 00503-211
ITEM QTY. PART NUMBER
1 1 FRME 00213 002
2 1 FRME 00202 002
3 2 ANGL 00191 002
4 2 ANGL 00190 002
5
4 UBOT 00007 000
6 HDWE 01154 0P0
4
7 12 HDWE 04003 0E0
8 12 HDWE 03003 0E0
9 6 HDWE 02073 0P0
10 6 HDWE 05004 0E0
11 6 HDWE 04002 0E0
12 6 HDWE 03002 0E0
13 4 HDWE 01134 000
14 12002-100
15 1 XELC 12002 200
16 1 ELEC 00013 100
17 1 ELEC 00140 000
18 1 ELEC 00064 000
19 1 ELEC 00126 0G0
20 2 ELEC 00221 002
-S
ENTER TRUT
W
DESCRIPTION
HEIGHT ADJUSTER ASSEMBLY
FAN BACKBOARD SUPPORT
SPAN ANGLE - 3'-4" Lg.
MOUNTING ANGLE - 9" Lg.
U-BOLT
1
1/2" x 1 " Lg. HEX HD. CAP SCREW (Grade 5)
4
1/2" LOCKWASHER
1/2" HEX NUT
1
3/8" x 1 " Lg. CARRIAGE BOLT (Grade 5)
4
3/8" FLATWASHER
3/8" LOCKWASHER
3/8" HEX NUT
3/8" x 1/2" Lg. NYLON BOLT
SPORTSONIC II TRANSMITTER
SPORTSONIC II RECEIVER
4-PRONG TWIST-LOCK PLUG
STRAIN RELIEF INSERT
3-PRONG TWIST-LOCK RECEPTACLE
1/2" DEEP COVER PLATE
CABLE TIE - 14" Lg.
H
EIGHT
S
ITH PORTSONIC
No. 00503-211 and 00603-506
No. 600 LINE MAST WITH RECTANGULAR BACKBOARD
ITEM QTY. PART NUMBER
1 1 FRME 00213 002
2 1 XEXT 91612 002
3 2 TUBS 00190
4 4 UBOT 00026
5
8 HDWE 04003 0E0
6 8 HDWE 03003 0E0
7 4 HDWE 01215 0E0
8 10 HDWE 05004 0E0
9 6 HDWE 04002 0E0
10 6 HDWE 03002 0E0
11 2 HDWE 02057 0E0
12 4 HDWE 01134 000
13 12002-100
14 1 XELC 12002 200
15 1 ELEC 00013 100
16 1 ELEC 00140 000
17 1 ELEC 00064 000
18 1 ELEC 00126 0G0
19 2 ELEC 00221 002
5
A
DJUSTMENT
II O
PERATION
PREV. NEXT
RAISE
LOWER
SPORTSONIC II
Gymnasium
Control System
PARTS LIST - No. 00603-506
DESCRIPTION
HEIGHT ADJUSTER ASSEMBLY
RECT. BACKBOARD EXTENSION
1
SPAN TUBE - 6'-4 " Lg.
4
U-BOLT
1/2" LOCKWASHER
1/2" HEX NUT
1
3/8" x 3 " Lg. HEX HD. CAP SCREW (Grade 5)
4
3/8" FLATWASHER
3/8" LOCKWASHER
3/8" HEX NUT
1
3/8" x 2 " Lg. CARRIAGE BOLT (Grade 5)
4
3/8" x 1/2" Lg. NYLON BOLT
SPORTSONIC II TRANSMITTER
SPORTSONIC II RECEIVER
4-PRONG TWIST-LOCK PLUG
STRAIN RELIEF INSERT
3-PRONG TWIST-LOCK RECEPTACLE
1/2" DEEP COVER PLATE
CABLE TIE - 14" Lg.
U
NITS
