PARTS LIST – KEY SWITCH OPERATION
C
Nylon spacer
(2) located
between fan
backboard
support and
backboard
500 LINE MAST WITH
FAN BACKBOARD
PARTS LIST - No. 00501-211
ITEM QTY. PART NUMBER
FRME 00213 002
1 1
2 1 FRME 00202 002
3 2 ANGL 00191 002
4 2 ANGL 00190 002
5 4 UBOT 00007 000
6 4 HDWE 01154 0P0
7 12 HDWE 04003 0E0
8 12 HDWE 03003 0E0
9 6 HDWE 02073 0P0
10 6 HDWE 05004 0E0
11 6 HDWE 04002 0E0
12 6 HDWE 03002 0E0
13 4 HDWE 01134 000
14 1 ELEC 00086 000
-S
ENTER TRUT
DESCRIPTION
HEIGHT ADJUSTER ASSEMBLY
FAN BACKBOARD SUPPORT
SPAN ANGLE - 3'-4" Lg.
MOUNTING ANGLE - 9" Lg.
U-BOLT
1
1/2" x 1 " Lg. HEX HD. CAP SCREW (Grade 5)
4
1/2" LOCKWASHER
1/2" HEX NUT
1
3/8" x 1 " Lg. CARRIAGE BOLT (Grade 5)
4
3/8" FLATWASHER
3/8" LOCKWASHER
3/8" HEX NUT
3/8" x 1/2" Lg. NYLON BOLT
KEY SWITCH ASSEMBLY
H A
EIGHT
W K S
ITH EY
No. 00501-211 and 00601-506
600 LINE MAST WITH
RECTANGULAR BACKBOARD
PARTS LIST - No. 00601-506
ITEM QTY. PART NUMBER
FRME 00213 002
1 1
2 1 XEXT 91612 002
3 2 TUBS 00190
4 4 UBOT 00026
5 8 HDWE 04003 0E0
6 8 HDWE 03003 0E0
7 4 HDWE 01215 0E0
8 10 HDWE 05004 0E0
9 6 HDWE 04002 0E0
10 6 HDWE 03002 0E0
11 2 HDWE 02057 0E0
12 4 HDWE 01134 000
13 1 ELEC 00086 000
3
DJUSTMENT
O
WITCH PERATION
DESCRIPTION
HEIGHT ADJUSTER ASSEMBLY
RECT. BACKBOARD EXTENSION
1
SPAN TUBE - 6'-4 " Lg.
4
U-BOLT
1/2" LOCKWASHER
1/2" HEX NUT
1
3/8" x 3 " Lg. HEX HD. CAP SCREW (Grade 5)
4
3/8" FLATWASHER
3/8" LOCKWASHER
3/8" HEX NUT
1
3/8" x 2 " Lg. CARRIAGE BOLT (Grade 5)
4
3/8" x 1/2" Lg. NYLON BOLT
KEY SWITCH ASSEMBLY
U
NITS
