SMAR TP290 Operation And Maintenance Instruction Manual

Position transmitter
Hide thumbs Also See for TP290:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP290 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMAR TP290

Summary of Contents for SMAR TP290

  • Page 2 Specifications and information are subject to change without notice. Up-to-date address information is available on our website. web: www.smar.com/contactus.asp...
  • Page 3 The TP290 is versatile and reliable, and has very high accuracy. It may be used for control valve stem position measurement, or in any other position sensing application such as louvers, dampers, crushers, etc.
  • Page 4 Smar provides specific training to instruct and qualify such professionals. However, each country must comply with the local safety procedures,...

  • Page 5: Table Of Contents

    REASSEMBLY PROCEDURE ............................ 4.2 SECTION 5 - TECHNICAL CHARACTERISTICS ..................1 FUNCTION SPECIFICATIONS ............................1 PERFORMANCE SPECIFICATIONS ..........................2 PHYSICAL SPECIFICATIONS............................2 APPENDIX A – SRF – SERVICE REQUEST FORM.................. A.1 RETURNING MATERIALS............................A.2 APPENDIX B – SMAR WARRANTY CERTIFICATE ................. B.1...
  • Page 6 TP290 – Operation and Maintenance Instruction Manual...

  • Page 7: Section 1 - Installation

    Mounting The mounting of transmitter TP290 will depend on type movement, if it is linear or rotary. Two supports are required for mounting, one for the magnet and the other for the transmitter itself.
  • Page 8 TP290 – Operation and Maintenance Instruction Manual modification, the transmitter will require a re-calibration. Fig. 1.1 – Dimensional Drawing of the TP290 and Magnet...
  • Page 9 Introduction Fig. 1.2 – Transmitter on the Rotary Actuator Fig. 1.3 – Transmitter on the Linear...

  • Page 10: Electronic Housing Rotating

    TP290 – Operation and Maintenance Instruction Manual Electronic Housing Rotating The electronic housing can be rotated in order to better position the digital display. To rotate it, use the Housing Rotation Set Screw, see Figure 1.4. Fig. 1.4 – Housing Rotation Set Screw The local indicator itself can also be rotated.
  • Page 11 The TP290 is protected against reverse polarity, and can withstand 50 mA without damage. The TP290 connection could be done conform the figure 1.7 and 1.8. It is also recommended to ground the shield of shielded cables at one end only. The non grounded end must be carefully isolated.
  • Page 12 TP290 – Operation and Maintenance Instruction Manual Fig. 1.8 – Load Curve...

  • Page 13: Section 2 - Operation

    PROM. For temporary storage of data there is a RAM. The data in the RAM is lost if the power is switched off, however the device also has a nonvolatile EEPROM where data that must be retained is stored. Examples of such data are: calibration and TP290 configuration. Fig. 2.1 –TP290 Block Diagram...
  • Page 14 Upon receiving power, the TP290 initializes the position indication on the display, by showing model TP290 and its software version (X.XX). Should the indication be higher than  1 9999 it will be displayed as a two digit and an exponent.

  • Page 15: Section 3 - Programming Using Local Adjustment

    In this section the “Magnetic Tool” will be referred to as “TOOL”, and the orifices identified by “S” and “Z” will be “ORIFICE S” and “ORIFICE Z”, respectively. Fig. 3.1 – Orifices of the Local Adjust Table 3.1- shows the results of what actions on “Z” and “S” cause on the TP290. ORIFICE ACTION Function browsing.

  • Page 16: Local Programming Tree

    TP290 – Operation and Maintenance Instructions Manual Local Programming Tree The programming tree is a tree shaped structure with a menu of all available software functions, as shown on Fig. 3.2. While in local Adjustment, it is possible to browse through all configuration options by keeping the magnetic tool in orifice “Z”.
  • Page 17 Programming Using Local Adjustment Fig. 3.3 – Tree of Programming of the Local Adjustment...
  • Page 18 TP290 – Operation and Maintenance Instructions Manual...

  • Page 19: Section 4 - Maintenance Procedures

    Section 4 MAINTENANCE PROCEDURES General SMAR TP290 to read Position are extensively tested and inspected before delivery to the end user. Nevertheless, during their design and development, consideration was given to the possibility of repairs by the end user, if necessary.

  • Page 20: Reassembly Procedure

    RETURNING MATERIALS Should it become necessary to return the transmitter to SMAR, simply contact your local agent or SMAR office, informing the defective instruments serial number, and return it to our factory. In order to expedite analysis and solution of the problem, the defective item should be returned with a description of the failure observed, with as many details as possible.
  • Page 21 Maintenance Procedures Fig. 4.2 – Four Possible Positions of the Indicator...
  • Page 22 TP290 - Operation and Maintenance Instruction Manual Fig. 4.3 – TP290 Exploded View...
  • Page 23 Maintenance Procedures ACCESSORIES ORDERING CODE DESCRIPTION SD-1 Magnetic Tool for local adjustment SPARE PARTS LIST CATEGORIA DESCRIPTION OF PARTS POSITION CODE (NOTE1) HOUSING, Aluminum (NOTE 2) - 14 NPT 301-0150 . M20 x 1.5 301-0151 . PG 13.5 DIN 301-0152 HOUSING, 316 SS (NOTE 2) - 14 NPT 301-0153...
  • Page 24 TP290 - Operation and Maintenance Instruction Manual...

  • Page 25: Section 5 - Technical Characteristics

    Section 5 TECHNICAL CHARACTERISTICS Function Specifications Travel Linear Motion: 3-100mm. Rotary Motion: 30-120º roation angle. Output Signal Two-wire, 4-20 mA. Reverse Polarity Protection 12 to 45 Vdc. Load Limitation Indicator Optional 4½ - digit numerical and 5-character alphanumerical LCD indicator. Hazardous Area Certifications Explosion proof, weather proof and intrinsically safe (CAPEL, FM, CENELEC standards pending).

  • Page 26: Performance Specifications

    TP290 - Operation and Maintenance Instruction Manual Actual Position Sensing Magnetic (Non-contact) via Hall Effect. Configuration Can be done through local adjust. Performance Specifications Reference conditions: range starting at zero, temperature 25ºC (77ºF), power supply of 24 Vdc. Accuracy Linearity, hysteresis and repeatability effects are included.
  • Page 27 Thechinical Characteristcs MODEL SMART POSITION TRANSMITTER – 4 to 20 mA TP290 CODE LOCAL INDICATOR With Digital Indicator CODE MOUNTING BRACKET Without Bracket With Bracket CODE ELECTRICAL CONNECTIONS 1/2 - 14 NPT M20 x 1.5 PG 13.5 DIN CODE TYPE OF MOTION...
  • Page 28 TP290 - Operation and Maintenance Instruction Manual smar...

  • Page 29: Appendix A - Srf - Service Request Form

    SRF – Service Request Form TP Position Transmitter GENERAL DATA Model: TP290 ( ) Firmware Version: ______________________ TP301 ( ) Firmware Version: _______________________ TP302 ( ) Firmware Version: ______________________ TP303 ( ) Firmware Version: _______________________ Serial _____________________________________ Sensor Number: __________________________________________...

  • Page 30: Returning Materials

    TP290 - Operation and Maintenance Instruction Manual Returning Materials Should it become necessary to return the transmitter and/or configurator to SMAR, simply contact our office, informing the defective instrument serial number, and return it to our factory. In order to speed up analysis and solution of the problem, the defective item should be returned with a description of the failure observed, with as much details as possible.

  • Page 31: Appendix B - Smar Warranty Certificate

    Appendix B SMAR WARRANTY CERTIFICATE SMAR guarantees its products for a period of 24 (twenty four) months, starting on the day of issuance of the invoice. The guarantee is valid regardless of the day that the product was installed. SMAR products are guaranteed against any defect originating from manufacturing, mounting,...
  • Page 32 13. It is the customer’s responsibility to clean and decontaminate products and accessories prior to shipping them for repair, and SMAR and its dealer reserve themselves the right to refuse the service in cases not compliant to those conditions. It is the customer’s responsibility to tell SMAR and its dealer when the product was utilized in applications that contaminate the equipment with harmful products during its handling and repair.
