Programming Menu

Power Supply Address ID (for use with Master/Slave setup)
1. Long press MENU to enter the settings menu
2. Turn the Voltage knob until you see 'Add' 'SEt' (address setting)
3. Press the Voltage knob to enter the address menu
4. Turn the Current knob to change the address ID (0~30). The Master unit must be set = 0.
Each Slave unit must have a unique ID (1 ~30).
5. Press the Voltage knob to confirm
6. Press MENU to exit

Factory Default Reset

1. Long press MENU to enter the settings menu
2. Turn the Voltage knob until you see 'FACS' 'SEt' (factory setting)
3. Press the Voltage knob to enter the address menu
4. Turn the Current knob to select no or yes
5. Press the Voltage knob to confirm selection
6. Press MENU to exit
Upper Voltage/Current (UVL/UCL) Limits
The Upper Voltage (UVL) and Current (UCL) Limits are added protection for sensitive loads. When
the output exceeds the UVL or UCL setting, the output signals will automatically switch OFF and
the alert icon 'Uul' or 'UCl' will appear. The second function of the Voltage and Current Knobs are
for UVL and UCL adjustment.
1. Press SHIFT and the SHIFT LED will switch ON.
2. Press the Voltage or Current knob. The display will show 'SUul' or 'SUCl' and the UVL or UCL
value on the 4-digit LEDs.
3. Turn the Voltage or Current knob to adjust the UVL or UCL value. Press the Voltage or
Current knob to select a digit for editing.
4. Press SHIFT to confirm the setting and to exit the mode. If the new value is lower than the
output setting, the DCP36 will display an error (Erro). In this case, reduce the output setting
to a value lower than the UVL or UCL value.

Stand-Alone Operation

1. With no load attached to either the front or rear output terminals, plug the power supply
into an AC power source.
2. Use the POWER button to switch the power supply ON.
3. The firmware version will briefly appear and then the 4-digit LEDs will read zero.
4. When connected to a load, the Voltage and Current knobs can be turned clockwise or
counterclockwise to increase or decrease the output levels for the selected preset A, B, or C
(see next section). View the adjustments on the 4-digit LED readouts. You can also short
