Specifications ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅4 - Panasonic CF-VEB071 Service Manual

1 Specifications
Item
CD-ROM Drive
Parallel Port
Interface External Display Port
Serial Port
Microphone Jack*
Headphone Jack
External Keyboard Port
External Mouse Port
Expansion Bus Connector
USB Port
LAN Port
Speaker
Sound
Power Supply Input
Environment
Physical Dimensions (W × D × H)
Weight
*
Use only a monaural condenser microphone.
Description
24X speed (max.)
Dsub 25-pin female
Mini Dsub 15-pin female
Dsub 9-pin male
Miniature jack, 3.5 DIA
Miniature jack, 3.5 DIA
Impedance 32 Ω, Output Power 4 mW × 2
Mini DIN 6-pin female
Mini DIN 6-pin female
Dedicated 100-pin female
4-pin
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
Monaural Speaker (built-in)
16 bits, 44.1 kHz AC '97 2.1 Compatible
DC 15.6 V [Use only the specified AC Adaptor
(Model No. CF-AA1639A)]
In Use Temperature
Humidity
Not in Use Temperature
Humidity
241 mm × 151 mm × 74 mm (9.5" × 5.9" × 2.9")
Approx. 1.1 kg {2.4 lb.}
4
5 °C to 35 °C
{41 °F to 95 °F}
30 % to 80 % RH
(No Condensation)
-20 °C to 60 °C
{-4 °F to 140 °F}
30 % to 90 % RH
(No Condensation)
