Panasonic CF-VEB071 Service Manual page 17

IC10 DA7787FSE2E
C47 82 84 DCSG1AB470RR
L16 17 18 DEAM51R0P506
X1 DECU25000L3U
D2 DEDRB715FT7
C14 36 ECST0JZ106R
C81 ECST1AX226R
C26 85 EEJK1AS106R
R55 ERJ12YJ3R3H
R3 25 75 84 ERJ3GEY0R00V
R18 5 ERJ3GEYJ102V
R12 15 19 30 31 ERJ3GEYJ103V
32 36 39 51 52 53
57 58 60 61
R22 33 59 ERJ3GEYJ104V
R49 50 ERJ3GEYJ273V
R37 38 ERJ3GEYJ222V
R56 87 ERJ3GEYJ330V
R76 77 89 ERJ3GEYJ470V
R26 27 28 ERJ3GEYJ472V
R16 17 34 35 ERJ3GEYJ473V
R54 81 ERJ3GEYJ474V
CA6 7 EZASCE101M
C76 77 DCUM1A1051BD
C38 39 58 68 109 ICUV1A105ZFS
C41 42 43 45 66 F1H1C2240006
C17 18 F1H1E104A056
C12 F1L3D102A003
L15 G1C100KA0002
L13 14 DDAZS22NJT4T
L2 G5B1C0000001
X2 DECU24576L3U
IC2 H1A1435B0010
C11 13 15 20 35 ICUV1E104ZFS
37 44 49 57 61 63
65 69 80 83 86
110 113
C60 64 ICUV1H100DCS
C111 112 114 115 ICUV1H101JCS
C46 55 56 73 75 ICUV1H102KBS
C27 28 51 502 ICUV1H103ZFS
C33 34 ICUV1H150JCS
C1 3 ICUV1H220JCS
C90 91 92 93 501 ICUV1H221KBS
C87 ICUV1H330JCS
C62 ICUV1H471JCS
L9 10 DDB5Z032A-L
L8 11 DDB5Z031J-L
L3 23 DDB5Z028C-L
IC, BI-POLAR LINEAR
CAPACITOR, 10V, 47µF
FERRITE BEAD
OSCILLATOR, 25MHz
DIODE
CAPACITOR, 6.3V, 10µF
CAPACITOR, 10V, 22µF
CAPACITOR, 10V, 10µF
RESISTOR, 1/2W, 3.3Ω
RESISTOR, 1/16W, 0Ω
RESISTOR, 1/16W, 1KΩ
RESISTOR, 1/16W, 10KΩ
RESISTOR, 1/16W, 100KΩ
RESISTOR, 1/16W, 27KΩ
RESISTOR, 1/16W, 2.2KΩ
RESISTOR, 1/16W, 33Ω
RESISTOR, 1/16W, 47Ω
RESISTOR, 1/16W, 4.7KΩ
RESISTOR, 1/16W, 47KΩ
RESISTOR, 1/16W, 470KΩ
CAPACITOR ARRAY
CAPACITOR, 10V, 1µF
CAPACITOR, 10V, 1µF
CAPACITOR, 16V, 0.22µF
CAPACITOR, 25V, 0.1µF
CAPACITOR, 2000V, 1000pF
INDUCTOR
INDUCTOR
PULSE TRANSFORMER
OSCILLATOR, 24.576MHz
IC, CRYSTAL (14.318MHz)
CAPACITOR, 25V, 0.1µF
CAPACITOR, 50V, 10pF
CAPACITOR, 50V, 100pF
CAPACITOR, 50V, 1000pF
CAPACITOR, 50V, 0.01µF
CAPACITOR, 50V, 15pF
CAPACITOR, 50V, 22pF
CAPACITOR, 50V, 220pF
CAPACITOR, 50V, 33pF
CAPACITOR, 50V, 470pF
FERRITE BEAD
FERRITE BEAD
FERRITE BEAD
10-3
1
3
3
1
1
2
1
2
1
4
2
15
3
2
2
2
3
3
4
2
2
2
5
5
2
1
1
2
1
1
1
18
2
4
5
4
2
2
5
1
1
2
2
2
