ORDER NO. ITD0410045C0 BNC HD-SDI Terminal Board TY-FB7HD CONTENTS Page Page 1 Safety Precautions 6 Block and Schematic Diagram 1.1. General Guidelines 6.1. Schematic Diagram Notes 2 Prevention of Electro Static Discharge (ESD) to 6.2. HI-Board Block Diagram Electrostatically Sensitive (ES) Devices 6.3. -
Page 2: Safety Precautions
TY-FB7HD 1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed. -
Page 3: Prevention Of Electro Static Discharge (Esd) To Electrostatically Sensitive (Es) Devices
TY-FB7HD 2 Prevention of Electro Static Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"... -
Page 4: About Lead Free Solder (Pbf)
TY-FB7HD 3 About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). -
Page 5: Connection
TY-FB7HD 4 Connection... - Page 6 TY-FB7HD...
-
Page 7: Circuit Board Layout
TY-FB7HD 5 Circuit Board Layout 5.1. HI-Board Parts Location Hl-BOARD IC3501 IC3502 IC3302 IC3503 IC3303 IC3304 TRANSISTOR IC3305 Q3301 IC3306 IC3307 IC3310 TP3301 IC3402 TP3302 IC3403 TP3401 IC3404 TP3401 IC3405 HI-BOARD (FOIL SIDE) HI-BOARD (COMPONENT SIDE) TXNHA10TNS TXNHA10TNS SLOT 1 2 3... - Page 8 TY-FB7HD...
-
Page 9: Block And Schematic Diagram
TY-FB7HD 6 Block and Schematic Diagram 6.1. Schematic Diagram Notes... -
Page 10: Hi-Board Block Diagram
TY-FB7HD 6.2. HI-Board Block Diagram H3302 10 6 IC3501 IC3503 H3300 IC3402 IC3404 AVR 1.5V AVR 3.3V RESET FPGA CONFIG ROM +1.5V +3.3V IC3302 SDI INPUT DATA EQUALIZER ASDI JK3301 +3.3V +3.3V DCLK +3.3V SERIAL IN IC3502 SW3301 MODE SW AVR 1.8V... -
Page 11: Hi-Board (1 Of 2) Schematic Diagram
TY-FB7HD 6.3. HI-Board (1 of 2) Schematic Diagram HI-BOARD TXNHA10TNS (1/2) EQUALIZER R3501 IC3302 C1AB00001653 CD_L/MUTE C3308 C3305 0.1u 0.1u SDI INPUT C3301 C3311 JK3301 6.3V 6.3V K1QBB1BB0014 4.7u SDI_P SDO_P R3301 SDI_N SDO_N C3302 C3312 6.3V 6.3V 4.7u R3302... -
Page 12: Hi-Board (2 Of 2) Schematic Diagram
TY-FB7HD 6.4. HI-Board (2 of 2) Schematic Diagram HI-BOARD TXNHA10TNS (2/2) AVR 3.3V IC3503 FL3308 C0CBCBD00008 ELKE103FA 5V>3.3V C3527 C3526 C3534 C3533 C3523 6.3V 0.1u 0.1u C3525 IC3502 AVR 1.8V 0.1u FL3307 C0CBCAD00015 ELKE103FA 3.3V>1.8V C3521 C3520 C3536 C3535 C3517 MODE SW 6.3V... -
Page 13: Replacement Parts List
TY-FB7HD 7 Replacement Parts List 7.1. Replacement Parts List Notes... -
