Clicking this button reduces the output level of the Speakers by an amount defined within
the AudioFuse Studio Preferences window
original setting. See
more information.
Spk B
Two sets of monitor speakers can be connected to the AudioFuse Studio, and this button lets
you switch between them for the selected output (Speakers or Phones 2). On the physical
unit the Output Level knob controls the level for the Speakers, and the second Phones knob
controls the level for Phones 2. The Master faders in the Monitoring Mix section can also
control the levels, depending on the selected source for the specific Analog Output.
Remember, there are two configuration options available in the Audio Settings window that
can be used to link and offset the speaker levels.
Re-Amp
This button activates the Re-Amping feature for that Aux output (Left or Right. You can use
both if needed). This causes the Aux output to switch its impedance to match the input on
a guitar amplifier, enabling you to route a "clean" guitar recording into the guitar amp and
re-record its output.
Link
This button toggles the state of the Aux L and Aux R outputs between linked and unlinked.
When linked they become a stereo pair, with a shared source and level. When unlinked their
sources and levels can be different.

2.4.3.2. Digital Outputs

The source for each pair of Digital Outputs can be selected. For example, there are four
options for digital outputs 1-2: Cue Mix, USB In 1-2, or Analog In 1-2.
This table lists all of the input / output routing options that are available in the selection menu
for each digital output.
ADAT Out 1-2
Main Mix
Cue Mix 1
Cue Mix 2
USB [1]
ADAT IN 1-2
[1] The USB input channels for these outputs are the ones routed to them via the DAW or
another computer source.
60
Audio Settings: AudioFuse Studio [p.45]
ADAT Out 3-4 ADAT Out 5-6
Main Mix Main Mix
Cue Mix 1 Cue Mix 1
Cue Mix 2 Cue Mix 2
USB [1] USB [1]
ADAT IN 3-4 ADAT IN 5-6
[p.50]. Click it again to restore the level to its
in the Menu bar chapter [p.42]
ADAT Out 7-8
Main Mix
Cue Mix 1
Cue Mix 2
USB [1]
ADAT IN 7-8
Arturia - User Manual AudioFuse Studio - AudioFuse Control Center
S/PDIF Loopback
Main Mix Main Mix
Cue Mix 1 Cue Mix 1
Cue Mix 2 Cue Mix 2
USB [1] Disabled
Speaker
SPDIF IN 1-2
