1.5.5.2. Audio Mapping at 88.2 / 96 kHz sampling rates:

Input Computer Input (REC)
1 Input Channel 1
2 Input Channel 2
3 Input Channel 3
4 Input Channel 4
5 Line Input 5 / Phono (Input 5)
6 Line Input 6 / Phono (Input 6)
7 Line Input 7
8 Line Input 8 / Talkback
9 S/PDIF Left
10 S/PDIF Right
11 ADAT 1
12 ADAT 2
13 ADAT 3
14 ADAT 4
15 ADAT 5
16 ADAT 6
17 ADAT 7
18 ADAT 8

1.5.5.3. Audio Mapping at 176.4 / 192 kHz sampling rates:

Input Computer Input (REC)
1 Input Channel 1
2 Input Channel 2
3 Input Channel 3
4 Input Channel 4
5 Line Input 5 / Phono (Input 5)
6 Line Input 6 / Phono (Input 6)
7 Line Input 7
8 Line Input 8
9 S/PDIF Left
10 S/PDIF Right
32
Computer Output (Playback)
Main Left
Main Right
Cue 1 Left
Cue 1 Right
Cue 2 Left
Cue 2 Right
Aux Out Left
Aux Out Right
S/PDIF Left
S/PDIF Right
ADAT 1
ADAT 2
ADAT 3
ADAT 4
ADAT 5
ADAT 6
ADAT 7
ADAT 8
Computer Output (Playback)
Main Left
Main Right
Cue 1 Left
Cue 1 Right
Cue 2 Left
Cue 2 Right
Aux Out Left
Aux Out Right
S/PDIF Left
S/PDIF Right
