Technical Specifications

Type
Rated Power
Frequency Response
Maximum SPL
Coverage
Transducers
Colors
Finishes
Material
Dimensions
(WxHxD)
Weight
IP Rating
Impedance
With dedicated preset.
1
Maximum SPL is calculated using a signall with crest factor 4 (12dB) measured at 1 m.
2
Maximum SPL is calculated using a signall with crest factor 4 (12dB) measured at 8 m then scaled at 1 m.
3
18
Lyzard-KZ1
Point source
3.5 W
500 Hz – 18 kHz (-6 dB)
1
86 dB (peak)
2
V. 140° | H. 140°
0,5" neodymium magnet woofer
Polished stainless steel, 24K gold finishes
22 x 37 x 11 mm
(0.9 x 1.5 x 0.4 in)
0.021 kg (0.046 lb)
16 Ω
Lyzard-KZ14
Line array
15 W
500 Hz – 18 kHz (-6 dB)
1
98 dB (peak)
3
V. 40° | H. 140°
4x 0,5" neodymium magnet woofers
Black, white, custom RAL
Aluminum
22 x 100 x 11 mm
(0.9 x 3.9 x 0.4 in)
0,059 kg (0.130 lb)
IP64
16 Ω
Vyper-KV25
Line array
75 W
150 Hz – 18 kHz (-6 dB)
1
108 dB (peak)
3
V. 25° | H. 120°
4x 1" neodymium magnet woofers
Brushed and polished stainless steel,
24K gold finishes
40 x 260 x 22 mm
(1.6 x 10.2 x 0.9 in)
0,4 kg (0.88 lb)
8 Ω / 32 Ω selectable
