SnapSAN S3000/S5000 Snapshot User Guide
Number of SVs
Displays the number of snapshot-volumes set in the base-volume.
Number of Active SVs
Displays the number of snapshot-volumes set in the base-volume whose snapshot status is
active.
Number of Cancelled SVs
Displays the number of snapshot-volumes set in the base-volume whose snapshot status is
released.
Snapshot Volume List
The snapshot-volume list displays the information about the items described below. Double-
clicking an item switches the display to the base-volume unit list corresponding to the
selected item.
Type
Displays the volume type.
SV Number
Displays the logical disk number of the snapshot-volume in hexadecimal.
10400422-002 02/2013
Display Description
Indicates an FC disk.
FC
Indicates an ATA disk.
ATA
Indicates a SAS (SED) disk.
SAS (SED)
Indicates an NLSAS disk.
NLSAS
Icon Description
Represents a snapshot-volume (SV).
If the snapshot is released, the icon changes to
If a snapshot fault or SV prepare fault occurred, the icon changes to
.
©2013 Overland Storage, Inc.
Figure 5-10:
.
