SnapSAN S3000/S5000 Snapshot User Guide
Summary/Details
Clicking the [Execute] button displays the following confirmation dialog.
[Execution Conditions]
To execute the snapshot guard operation, the following conditions must be satisfied.
• The target snapshot-volume is in the active, restore preparing, or restoring state.
• The target snapshot-volume is not guarded.
• The disk array is being monitored.
• The disk array is not in the freeze state.
• The state of the target base-volume is not restore fault.
• The state of the target base-volume is not snapshot fault.
• If the target base-volume is also used as MV, the synchronous state of the pair is not
Separate Preparing, Sync Preparing, or Restore Preparing.
10400422-002 02/2013
Unexecutable Information Action
Snapshot Inactive
Snapshot Deleting
SV Guard
Monitoring Suspended
Freezing
Restore fault
SV fault
SV Preparing
SV Prepare Fault
©2013 Overland Storage, Inc.
Execute the operation for a snapshot-volume whose
snapshot state is active.
Execute the operation for a snapshot-volume whose
snapshot state is active.
The snapshot is already guarded.
Retry after restarting the monitoring of the disk array.
Retry after defreezing the replication function.
This operation cannot be executed because a restore fault
occurred in the target base-volume.
This operation cannot be executed because a snapshot
fault occurred in the target base-volume.
Execute the operation for a snapshot-volume whose
snapshot state is active.
Execute the operation for a snapshot-volume whose
snapshot state is active.
Figure 5-89: Execute
 5-88
