SnapSAN S3000/S5000 Snapshot User Guide
Clicking the [Execute] button displays the following confirmation dialog.
Clicking the [Yes] button displays the following dialog indicating the system is during
processing.
The Processing dialog displays information for the base volume currently being processed.
Clicking the [Cancel] button displays the following dialog. From this dialog, you can suspend
cyclic snapshot creation and return to the Snapshot Management screen for other
operations. You can also check the object snapshot state of the selected base volume from the
information list display area of the Snapshot Management screen.
10400422-002 02/2013
Unexecutable Information Action
Freezing
Replication Operating
Restore fault
SV fault
BV Data Being Migrated
Figure 5-66: Cyclic Creation Execute
Figure 5-68: Cancellation Message Dialog
©2013 Overland Storage, Inc.
Retry after defreezing the replication function.
This operation cannot be executed during the replication
operation.
This operation cannot be executed because a restore fault
occurred in the target base-volume.
This operation cannot be executed because a snapshot
fault occurred in the target base-volume.
Retry after data migration is completed.
Figure 5-67: Processing Dialog
