Module Rf Receive Sensitivity; Module Operating Frequencies - SimCom SIM800 Hardware Design

Table 45: DCS 1800 and PCS 1900 conducted RF output power
PCL Nominal output power (dBm)
0 30
1 28
2 26
3 24
4 22
5 20
6 18
7 16
8 14
9 12
10 10
11 8
12 6
13 4
14 2
15 0

6.11 Module RF Receive Sensitivity

The following table shows the SIM800 conducted receive sensitivity; it is tested under static condition.
Table 46: Conducted RF receive sensitivity
Frequency
GSM850,EGSM900
DCS1800,PCS1900

6.12 Module Operating Frequencies

The following table shows the module's operating frequency range; it is followed by the 3GPP TS 05.05
technical specification requirement.
SIM800_Hardware Design_V1.10
DCS1800,PCS1900
Normal
±2
±3
±3
±3
±3
±3
±3
±3
±3
±4
±4
±4
±4
±4
±5
±5
Receive sensitivity(Typical)
< -108dBm
< -108dBm
57
Smart Machine Smart Decision
Tolerance (dB) for conditions
Extreme
±2.5
±4
±4
±4
±4
±4
±4
±4
±4
±5
±5
±5
±5
±5
±6
±6
Receive sensitivity(Max)
< -106dBm
< -106dBm
2018-08-13
