The serial port supports the CMOS level. If user connects the module to the computer, the level shifter should be
added between the DCE and DTE.

4.6. RI Behaviors

Table 11: RI Behaviors
State RI response
Standby High
The pin is changed to low. When any of the following events occur, the pin will be
changed to high:
Voice call
(1)Establish the call
(2)Hang up the call
The pin is changed to low. When any of the following events occur, the pin will be
changed to high:
Data call
(1)Establish the call
(2)Hang up the call
The pin is changed to low, and kept low for 120ms when a SMS is received. Then it is
SMS
changed to high.
The pin is changed to low, and kept low for 120ms when some URCs are reported. Then it
URC
is changed to high. For more details, please refer to document [10].
