Setpoint groups

1. ProcessControl
2. Basic settings
3. Comms settings
4. ComProtSettings
5. Analog protect
6. Bank protect
7. Pwr Management
8. Sync/Load ctrl
9. Volt/PF ctrl
10. Force value
11. Load shedding
12. Timer settings
13. Act. calls/SMS
14. Date/Time
C !
AUTION
Do not perform repeated writing of setpoints (e.g. power control from a PLC by repeated writing of baseload
setpoint via Modbus) The setpoints are stored in EEPROM memory, which can be overwritten more than 10
times without risk of damage or data loss, but it may become damaged, when allowed number of writing
cycles is exceeded!
H
INT
The descriptions of all available setpoints, values logical binary inputs and logical binary outputs that you can
find in next chapters are common for standard gen-set in MINT application and the Bank Controller. For the
purpose of this document, please consider the term "gen-set" as "Bank Controller".

Table of setpoints

Group: ProcessControl
Setpoint: #SysBaseLoad
Group Process Control
Range [units] 0 .. 65000 [kW]
Related FW 3.0
Description This setpoint is used to adjust the requested load for the whole gen-set group
in system baseload mode (i.e.
takes proprtionally equal part of this total required value. The number of running
gen-sets is resolved by the
requested total load, gen-sets nominal power and adjusted reserves.
Setpoint: LocalBaseload
Group Process control
Range [units] OFF, 1 ..
Related FW 3.0
Force value YES
IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
#SysLdCtrl PtM
power management function
Nomin power [kW]
= BASELOAD). Each gen-set
according to the
