- Page 1 Model Document Vallox 90 MV D5316 Vallox 90K MV Valid from Type 30.03.2020 A3527 A3528 Updated 16.03.2020 Manual Ventilation units...
-
Page 2: Table Of Contents
Vallox 90 MV, 90K MV ........ -
Page 3: Safety
Structural or electronic modifications or changes made to the device. software INTENDED USE All Vallox ventilation units have been designed to provide appropriate and continuous ventilation so as to present no threat to health and to maintain structures in good condition. IMPORTANT... -
Page 4: Safety Signs Used In The Instructions
INSTALLATION OPTIONS NOTE The standard equipment and • Vallox 90 MV can be mounted either on the wall, or on the ceiling by using available accessories a mounting plate (optional). vary from country to • Vallox 90K MV can only be mounted on the wall. -
Page 5: Ventilation Unit Control
For the MyVallox Cloud/ Home instructions, Ventilation unit control options. please go to www. techmanuals.info/ ValloxMV/ENG/ Operation of the Vallox ventilation unit can be controlled by the onlinehelp/webhelp following means: • Through the My Vallox Control panel installed in the building. •... -
Page 6: Main Parts
MAIN PARTS Vallox 90 MV R model in the figure Post-heating resistor Extract air fan Safety switch Supply air fan Internal humidity sensor Fine filter for supply air Internal carbon dioxide sensor Heat recovery cell Control panel Bypass damper of the HR cell... -
Page 7: Main Parts
Bypass damper of the HR cell Humidity sensor (optional) Coarse filter for supply air VOC sensor (Optional) Coarse filter for extract air Cooker hood Post-heating resistor Damper button Safety switch Fan speed adjustment © Vallox Oy - All rights reserved... -
Page 8: Installation
Make sure that the unit is horizontally level after mounting. MOUNTING ON THE CEILING Model Vallox 90 MV can be equipped with an optional ceiling mount plate. To attach the ceiling mounting plate: • To the ceiling with M8 thread bars so that they stand the weight of the unit. -
Page 9: Installing The Ventilation Unit To The Ceiling Mounting Plate
You can detach the unit from the ceiling mounting plate by pulling the spring- loaded moulding to the direction shown by the arrow (more detailed information provided with the ceiling mounting plate). © Vallox Oy - All rights reserved... -
Page 10: Vallox 90K Mv
The accessories delivered with the unit include four (4) air flow measuring tubes. These can be inserted in the ducts to allow for easier ventilation adjustment. NOTE The Vallox Silent Klick siphon package is delivered with the unit. Installation instructions... -
Page 11: Vallox 90 Mv, 90K Mv
4. Exhaust air flowing outdoors from the unit L model Measurement points after the outlet collar. The fan curves indicate the total pressure accounted for by duct losses. A Supply air Extract air C Supply D Extract © Vallox Oy - All rights reserved... -
Page 12: Maintenance
When the maintenance reminder becomes activated, check the cleanliness of the filters and replace them if required. The Vallox ventilation unit has three air filters: • Coarse filter for supply air filters insects, heavy pollen and other relatively large foreign objects out of the Using original Vallox filters ensures outdoor air. -
Page 13: Cleaning The Heat Recovery Cell
To check this, WARNING pour some water into the pool. Clean as required. Water must at all times be kept out of the electrical system. © Vallox Oy - All rights reserved... -
Page 14: Cleaning The Fans
Disconnect the ventilation unit from the mains electricity them. supply. Handle the fan blades 2. Lift the latch to open the door of the Vallox ventilation unit. carefully. Do not 3. Lift the door off. remove or move the fan blade balancing CAUTION weights. -
Page 15: Vallox 90K Mv
To replace the cooker hood lamp (type PL 11, 11 W), remove the protective glass of the lamp (A) by pushing it to the left. Once you have replaced the lamp, put the protective glass back in its place. © Vallox Oy - All rights reserved... -
Page 16: Technical Specifications
TECHNICAL SPECIFICATIONS Product title Product number Vallox 90 MV R 3571400, 3571600 Vallox 90 MV L 3571500, 3571700 Air volumes Fans Supply air 73 dm /s, 100 Pa Supply air 0.119kW, 0.9A EC Extract air 84 dm /s, 100 Pa Extract air 0.119kW, 0.9A EC Post-heating Electrical resistor, 900 W... -
Page 17: Internal Electrical Connection
D/I2 Digital input 2 130°C overheating protection 11V1 11.1 V operating voltage AN/I Analog input 0-10VDC RM/I 24V relay input CABLE COLOURS RM/O 24V relay output Blue Brown White Grey Yellow YEGN Yellow-green © Vallox Oy - All rights reserved... -
Page 18: Vallox 90K Mv
5. Supply air from the HR cell D/I2 Digital input 2 11V1 11.1 V operating voltage Hood connector AN/I Analog input 0-10VDC Vallox 90 K SC Hood RM/I 24V relay input RM/O 24V relay output CABLE COLOURS Black Blue Brown... -
Page 19: External Electrical Connection
Analog input 0-10VDC MyVallox CO sensor 1.2W RS_A Local hardware Modbus A signal RM/I 24V relay input Voltage 24 VDC RS_B Local hardware Modbus B signal RM/O 24V relay output External temperature sensor connector © Vallox Oy - All rights reserved... -
Page 20: Duct Radiator Operation
DUCT RADIATOR OPERATION Always follow first and foremost the connection diagram provided by the HVAC designer or heat pump manufacturer. If the duct NOTE: Also read the duct radiator manual. radiator is used in the supply air duct, it The accompanying figure shows an example of the can only be used for arrangement for connecting the heating/cooling radiator unit cooling. -
Page 21: Duct Radiator Operation Chart
Feed from the distribution board External electrical junction box for the MV Air extraction External NTC sensor for Vallox MV ventilation units Duct radiator (reverse connection) 24 VDC relay/contactor for controlling the pump and the solenoid valve. Not included in the delivery. -
Page 22: External Electrical Connection For Controlling The Mlv Duct
EXTERNAL ELECTRICAL CONNECTION FOR CONTROLLING THE MLV DUCT RADIATOR 24 VDC relay/ Distribution board contactor for controlling the pump and solenoid valve +24VDC External temperature sensor NTC 4K7 MLV control Ethernet connection on top of the unit Plug connection 1.2 m on top of the unit VENTILATION UNIT INTERNAL ELECTRICAL CONNECTION RJ45 Female... -
Page 23: Exploded View And Parts List
935360 Name plate 990991 Rubber cushion of the fan 975040 Door latch 3355900 Summer/winter damper assembly (specify whether left- or right- 3372800 MyVallox Control panel 949033 handed in the order) © Vallox Oy - All rights reserved... -
Page 24: Vallox 90K Mv
Vallox 90K MV 21 22 NO. PART CODE NO. PART CODE NO. PART CODE Side panel 3239010 Lid of the electric box 3456100 Finger screws 990710 Door 3259900 Condensing water outlet 3494701 Cover door mount 3295800 Wall mounting plate 3080700 14b. -
Page 25: Conformity Certificates
CONFORMITY CERTIFICATES... - Page 27 © Vallox Oy - All rights reserved...
- Page 28 Vallox Oy | Myllykyläntie 9-11 | 32200 LOIMAA | FINLAND Customer service +358 10 7732 200 | Aftersales +358 10 7732 270 © Vallox Oy - All rights reserved...
