© Vallox
1.09.351 E
17.1.2019
1
Extract air fan
2
Supply air fan
3
Post-heating radiator
(electric 900 W)
4
Heat recovery cell
5
Outdoor air filter F7
6
Outdoor air filter G4
7
Extract air filter G4
8
Automatic summer/winter damper
9
Safety switch
10 Measurement outlets
(behind an opening door)
11 Adjustment of the relationship
between supply and extract air
12 Adjustment of supply air
temperature and summer/
winter function
Vallox
90
Low-energy ventilation unit
with heat recovery
Operating, maintenance and technical instructions
10
The measurement outlets are
located behind the machine
plate. Detach the machine
plate by pushing it to the left
and pull the outlets out.
TECHNICAL DATA
Electrical connection
Degree of protection provided by enclosures
Fans
Extract air
direct current (DC) Supply air
Heat recovery
Heat recovery bypass
Electric post-heating unit
Fans
Supply air
Extract air
Weight
Ventilation control
K
MC
7
6
9
11
12
3
2
4
5
8
The figure shows the R model
230V 50Hz = 5.7A
IP34
0.119 kW 0.9A 92dm
0.119 kW 0.9A 75dm
Cross-counter flow heat recovery cell, h> 80%
Automatic
900 W, 3.9 A
G4 and F7
G4
52 kg
Cooker hood
Code
3524
Models
VALLOX 90K MC R
VALLOX 90K MC L
1
/s 50Pa
3
/s 50Pa
3
