VALLOX 90 SE R
VALLOX 90 SE L
DIGIT
ELECTRONIC CONTROLLER
WITH LCD DISPLAY
• Highly efficient heat recovery ( > 80 %)
• Energy-efficient integrated direct-current fans
• Electronic Vallox Digit SED adjustment
system enables automatic ventilation
adjustment
• Wireless remote monitoring possible
(option)
• Preheating with electric radiator
• Post-heating with electric radiator
• Electronically controlled automatic
antifreeze
• Automatic heat recovery cell
bypass during summer
• Good outdoor air filtering (F7)
• Fireplace/booster function
• Maintenance reminder
• Humidity sensor
• Carbon dioxide sensor
• Can be connected to data networks (LON)
• Elegant design
• Handy door locking mechanism
• Fixed air flow measuring outlets
© VALLOX • We reserve the right to make changes without prior notification.
Vallox
90
SED
Electrical connection
Class of protection
Fans
direct current (DC) Supply air
Heat recovery
Heat recovery bypass
Electric preheating unit (standard equipment)
Electric post-heating unit (option)
Filters
Weight
Power adjustment of ventilation
Options
SE
230 V, 50 Hz, ≈5 A
(+ post-heating radiator 3.9 A)
IP 34
Extract air 0.119 kW 0.9 A 92 dm
0.119 kW 0.9 A 75 dm
Cross-counterflow cell, > 80%
max. 1000 W 4.3 A
max. 900 W 3.9 A
Supply air
G4 and F7
Extract air
G4
52 kg
- control via control panel
- CO
- remote monitoring control
(LON converter)
- remote monitoring control
(voltage/current signal)
- CO
- %RH sensor
- LON converter
- Insulated attic floor penetration plate
- Ceiling mounting plate Vallox 90
• 1.09.331E
• 9.4.2013
• Code 3520
© VALLOX
Code 3520
Technical Research Centre of
Finland VTT certificate number
C326/05
3
/s 50 Pa
/s 50 Pa
3
Automatic
and %RH control
2
sensor
2
