A.5 Spare parts/accessories
A.5.3

Spare part OXYMAT 7 - field device

Table A-11 Spare parts list OXYMAT 7 - field module
Order number Name
A5E03790045 Spare measuring head
A5E03790046 Spare measuring head
A5E03790049 Spare sample chamber
A5E03790050 Spare sample chamber
A5E03790052 Spare sample chamber w/o
vib. comp.; Hastelloy
A5E03790053 Spare sample chamber with
vib. comp.; Hastelloy
A5E03790507 Spare analyzer module PCB;
standard + screws
A5E03790512 Spare control module PCB
A5E03790513 Spare heater, sample cham‐
ber
A5E35671289 Pressure switch complete
A5E35678290 Set of flame arresters for SG
A5E35678342 Set of flame arresters for SG
A5E35678359 Set of flame arresters purge
connector
A5E35679015 Flame arrester for VG
A5E35679443 Set for breathing apparatus
complete
A5E35679468 Set of pipes + nuts M10 + O-
ring 1/8"
Kalrez 6378 O-rings
1.78x3.68
A5E35679470 Set of pipes + O-ring 1/16"
FKM O-ring 1.78 x 3.68
A5E35681466 Union nut (set)
A5E35681542 Set of cables complete
A5E35681566 Main cable 7 meters
A5E35681883 Fuses (set)
A5E35682347 PCB connection board +
screws
106
Description
Measuring head, variant without vibration compensation, O-
rings only for measuring head (flange, screwed gland and at
the top bin section)
Measuring head, variant with vibration compensation
Sample chamber, variant without vibration compensation;
stainless steel (1.4571)
Measuring head included in product package
Sample chamber, variant with vibration compensation for
monitoring with pressure switch (variant without pressure
sensor); stainless steel (1.4571)
Measuring head included in product package
Sample chamber, variant without vibration compensation;
Hastelloy; T-piece; union nuts, cutting ring, clamping ring pre-
fitted on pipe
Hosed sample gas path.
Sample chamber, variant with vibration compensation; Has‐
telloy; piped sample gas path
Standard
Control module PCB
Heater, sample chamber; 72°C variant
Pressure switch, distributor, support plate, cable
Flame arrester SG; stainless steel
Flame arrester SG; Hastelloy
Flame arrester, purge gas connector
Flame arrester reference gas
Breathing apparatus
Stainless steel
without pressure switch
Set of union nuts, connected by customer; stainless steel
Cables with fasteners: Cable AD output, cable voltage supply,
cable analyzer module control board, cable CAN connection
Main cable, 7 meters
Replaceable fuses
APCB, connection board and screws
Operating Instructions, 05/2015, A5E35640463-02
Classifica‐
tion
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
1
2
2
2
2
Field device
