norbar EVOTORQUE Quick Reference Manual

QUICK REFERENCE GUIDE
EVOTORQUE
IMPORTANT:
IMPORTANT:
The instructions below are a brief guide for reference only, do not operate the tool before you have
read and understood the Operator's Manual supplied with the tool.
1. Ensure that the correct socket has been fitted to the tool. To fit a socket, first
slide the socket over the tool's square drive ensuring the socket's pin hole and
the square drive pin hole line up. Then slot the holding pin through the hole
and place the retaining ring over the holding pin to secure.
2. Lightly press the main trigger until the display turns on
3. Ensure the Clockwise/Counter-clockwise display arrow shown on screen is correct.
Press to change direction (if required).
NORBAR TORQUE TOOLS LTD, Wildmere Road, Banbury, Oxfordshire, OX16 3JU, UNITED KINGDOM
Part Number 34469 | Issue 2 | Original Instructions (English)
®
BATTERY TOOL (EBT)
IT IS VITAL THAT THE SAFETY INFORMATION IN THE
OPERATOR'S MANUALS (34464, 34466 AND 34468) HAVE BEEN
READ AND FULLY UNDERSTOOD BEFORE USING THIS TOOL.
TO RUN TOOL PRESS TRIGGER (A) AND 'SAFE TO START' BUTTON (A)
SIMULTANEOUSLY AS DEMONSTRATED ABOVE
Tel: + 44 (0)12965 753600
Email: enquiry@norbar.com | Website:
See step 7
